DALI to Modbus TCP and RTU

6.2. DALI to Modbus TCP and RTU

6.2.1. Modbus Registers

NOTICE
This part is common for Modbus RTU and TCP.
Function to read Modbus registers:
• 03 Read holding registers
• 04 Read input registers
Function to write Modbus registers:
• 06 Write single holding registers
• 16 Write multiple holding registers
Modbus register contents are expressed in most significant bit (MSB) .. less significant bit (LSB).
The following tables list all available Modbus registers for the gateway.
NOTE
For a complete gateway configuration guide, please refer to the
IN703DAL0640000.
NOTICE
Read/write parameter terminology:
• R: Read-only register
• W: Write-only register
• RW: Read and write register
• T: Trigger (The register activates an action and then returns to its default value).
Table 15. All ballasts
Register name
Ballast / Lamp Failure Bit Fields
ECG 15 .. 0
Ballast / Lamp Failure Bit Fields
ECG 31 .. 16
Ballast / Lamp Failure Bit Fields
ECG 47 .. 32
Ballast / Lamp Failure Bit Fields
ECG 63 .. 48
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
USER MANUAL Version 1.0.2
Possible values
0: OK
1: Ballast / Lamp Failure bi*
*i=xx-(16*(y-1))
0: OK
1: Ballast / Lamp Failure bi*
*i=xx-(16*(y-1))
0: OK
1: Ballast / Lamp Failure bi*
*i=xx-(16*(y-1))
0: OK
1: Ballast / Lamp Failure bi*
*i=xx-(16*(y-1))
Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Intesis MAPS User manual for
Address formula R/W
7000*y+0 R
7000*y+1 R
7000*y+2 R
7000*y+3 R
Channel
