Table 20. Color control (Type 8)
Object name
Uyxx_Store Current Level &
Colour as Scene
Uyxx_Clear/Remove Colour from
Scene
Uyxx_Arc Colour Level
Uyxx_Arc Colour White Level-
RGBW
For RGBW only
Uyxx_Colour Tc Step W/C
Uyxx_Actual Colour Level
Uyxx_Actual Colour White Level-
RBGW
For RGBW only
Uyxx_Power ON Colour
Uyxx_Power ON Colour White
Level-RGBW
Uyxx_System Fail Colour
Uyxx_Syst Fail Colour White
Level-RGBW
Uyxx_Min Colour Range (°K)
Uyxx_Max Colour Range (°K)
Uyxx_Set Power ON Colour
Uyxx_Set PWR ON Colour White
Level-RGBW
Uyxx_Set System Fail Colour
Uyxx_Set Syst Fail Colour White
Level-RGBW
Uyxx_Set Min Colour Range (°K)
Uyxx_Set Max Colour Range (°K)
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
Table 21. DALI groups - Color ballasts (Type 8)
Register name
Gyxx_Arc Colour level
Address formula:
y: Line number (0)
xx: Group number (0 .. 15)
Page 36 of 40
Possible values Object type
0 .. 15 1-Analog Output
0 .. 15 1-Analog Output
Tc: 1000 .. 10000°K
1-Analog Output
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 1-Analog Output
0: Step Cooler
4-Binary Output
1: Step Warmer
Tc: 1000 .. 10000°K
0-Analog Input
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 0-Analog Input
Tc: 1000 .. 10000°K
0-Analog Input
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 0-Analog Input
Tc: 1000 .. 10000°K
0-Analog Input
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 0-Analog Input
Tc: 1000 .. 10000°K 0-Analog Input
Tc: 1000 .. 10000°K 0-Analog Input
Tc: 1000 .. 10000°K
1-Analog Output
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 1-Analog Output
Tc: 1000 .. 10000°K
1-Analog Output
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 1-Analog Output
Tc: 1000 .. 10000°K 1-Analog Output
Tc: 1000 .. 10000°K 1-Analog Output
Possible values
Tc: 1000 .. 10000°K
RGB: 0 .. 251600
Object instance R/W
25000+(3200*y)+(100*xx)+0 W
25000+(3200*y)+(100*xx)+1 W
25000+(3200*y)+(100*xx)+2 W
25000+(3200*y)+(100*xx)+4 W
25000+(3200*y)+(100*xx)+5 W
25000+(3200*y)+(100*xx)+6 R
25000+(3200*y)+(100*xx)+8 R
25000+(3200*y)+(100*xx)
R
+10
25000+(3200*y)+(100*xx)
R
+12
25000+(3200*y)+(100*xx)
R
+14
25000+(3200*y)+(100*xx)
R
+16
25000+(3200*y)+(100*xx)
R
+18
25000+(3200*y)+(100*xx)
R
+20
25000+(3200*y)+(100*xx)
W
+22
25000+(3200*y)+(100*xx)
W
+24
25000+(3200*y)+(100*xx)
W
+26
25000+(3200*y)+(100*xx)
W
+28
25000+(3200*y)+(100*xx)
W
+30
25000+(3200*y)+(100*xx)
W
+32
Address formula R/W
7000*y+(20*xx)+6416 RW
