HMS Networks Intesis 700 Series User Manual
  1. Manuals
  2. Brands
  3. HMS Networks Manuals
  4. Gateway
  5. Intesis 700 Series
  6. User manual

HMS Networks Intesis 700 Series User Manual

Air gateway
Hide thumbs Also See for Intesis 700 Series:

Advertisement

Quick Links

Download this manual
ENGLISH
700series Air Gateway - IN775FGL⁎⁎⁎O000
                                                       FUJITSU VRF SYSTEMS
to Modbus, KNX, BACnet, and Home Automation
USER MANUAL
Version 1.0.11
Publication date 2024-09-04

Advertisement

loading
Need help?

Need help?

Do you have a question about the Intesis 700 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HMS Networks Intesis 700 Series

Summary of Contents for HMS Networks Intesis 700 Series

  • Page 1 ENGLISH 700series Air Gateway - IN775FGL⁎⁎⁎O000                                                        FUJITSU VRF SYSTEMS to Modbus, KNX, BACnet, and Home Automation USER MANUAL Version 1.0.11 Publication date 2024-09-04...
  • Page 2 The information in this document shall therefore not be construed as a commitment on the part of HMS Networks and is subject to change without notice. HMS Networks makes no commitment to update or keep current the information in this document.

  • Page 3: Table Of Contents

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Table of Contents 1. Description, Compatible AC systems, and Order Codes ..............1 2. Licensing ..........................2 3. General Information ........................ 3 3.1. Intended Use of the User Manual ..................3 3.2. General Safety Information ....................3 3.3.

  • Page 4: Description, Compatible Ac Systems, And Order Codes

    Description, Compatible AC systems, and Order Codes 700series Air Gateway - IN775FGL⁎⁎⁎O000 1. Description, Compatible AC systems, and Order Codes IN775FGL⁎⁎⁎O000 Gateway. Modbus®, KNX®, BACnet®, and Home Automation gateway for Fujitsu® HVAC systems. This gateway is compatible with VRF units commercialized by Fujitsu. Use the compatibility tool to get a complete list of compatible units: https://compatibility.intesis.com/ You can set up this Intesis gateway for Modbus TCP, Modbus RTU, KNX TP, BACnet/IP, BACnet MS/TP, or Home...

  • Page 5: Licensing

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Licensing 2. Licensing Distribution license(s) for the IN775FGL⁎⁎⁎O000 gateway: Maximum AC units Order Code License Indoor units Outdoor units IN775FGLXXSO000 IN775FGL00SO000 Small IN775FGL00MO000 Medium NOTE The order code may vary depending on the product seller and the buyer's location. Page 2 of 43 USER MANUAL Version 1.0.11...

  • Page 6: General Information

    General Information 700series Air Gateway - IN775FGL⁎⁎⁎O000 3. General Information 3.1. Intended Use of the User Manual This manual contains the main features of this Intesis gateway and the instructions for its appropriate installation, configuration, and operation. Any person who installs, configures, or operates this gateway or any associated equipment should be aware of this manual's contents.

  • Page 7: Admonition Messages And Symbols

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Admonition Messages and Symbols This Intesis gateway is designed for installation in an enclosure. When the device is mounted outside an enclosure, precautions should be taken to avoid electrostatic discharges to the unit in environments with static levels above 4 kV.

  • Page 8: Overview

    Overview 700series Air Gateway - IN775FGL⁎⁎⁎O000 4. Overview This IN775FGL⁎⁎⁎O000 gateway supports four combinations. Gateway's client interface ↔ Gateway's server interface Modbus TCP and RTU KNX TP Fujitsu VRF systems BACnet/IP or MS/TP Home Automation IMPORTANT This document assumes that the user is familiar with these technologies. Figure 1.

  • Page 9: Inside The Package

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Inside the Package Figure 3. Integration of Fujitsu units into BACnet systems Figure 4. Integration of Fujitsu units into Home Automation systems 4.1. Inside the Package ITEMS INCLUDED • Intesis IN775FGL⁎⁎⁎O000 Gateway • USB Mini-B type to USB Type-A cable •...

  • Page 10: Gateway General Functionality

    Gateway General Functionality 700series Air Gateway - IN775FGL⁎⁎⁎O000 • 2 x DIP switches for the EIA-485 connector termination and polarization configuration. • 14 LEDs indicate the operating status for both the gateway and the communication bus. • DIN rail and wall mounting case. •...

  • Page 11: Quick Start Guide

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Quick Start Guide 5. Quick Start Guide IMPORTANT While the following procedure outlines the fundamental steps for installing, wiring, and configuring the gateway, it is crucial to thoroughly review all documentation to prevent errors. Install Intesis MAPS on your laptop.

  • Page 12: Hardware

    Hardware 700series Air Gateway - IN775FGL⁎⁎⁎O000 6. Hardware 6.1. Mounting IMPORTANT Before mounting, please ensure that the chosen installation place preserves the gateway from direct solar radiation, water, high relative humidity, or dust. NOTE Mount the gateway on a wall or over a DIN rail. We recommend the DIN rail mounting option, preferably inside a grounded metallic industrial cabinet.
  • Page 13 700series Air Gateway - IN775FGL⁎⁎⁎O000 Mounting DIN RAIL MOUNTING Keep the clips in their original position. Fit the gateway’s top-side clips in the upper edge of the DIN rail. Press the low side of the gateway gently to lock it in the DIN rail. Make sure the gateway is firmly fixed.

  • Page 14: Connection

    Connection 700series Air Gateway - IN775FGL⁎⁎⁎O000 6.2. Connection CAUTION Disconnect all systems from power before manipulating and connecting them to the gateway. IMPORTANT Keep communication cables away from power and ground wires. 6.2.1. Gateway Connectors Figure 5. Wiring diagram USER MANUAL Version 1.0.11 Page 11 of 43...
  • Page 15 700series Air Gateway - IN775FGL⁎⁎⁎O000 Connection WIRING THE CONNECTORS IMPORTANT For all connectors, use solid or stranded wires (twisted or with ferrule). Cross-section/gauge per terminal: • One core: 0.2 .. 2.5 mm / 24 .. 11 AWG • Two cores: 0.2 .. 1.5 mm / 24 ..

  • Page 16: Connection To The Power Supply

    Connection 700series Air Gateway - IN775FGL⁎⁎⁎O000 6.2.2. Connection to the Power Supply The power supply connector is a green pluggable terminal block (three poles) labeled as Power. Apply the voltage within the admitted range and of enough power: • For DC: 12 .. 36 VDC (±10%), Max: 250 mA •...

  • Page 17: Connection To Modbus

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Connection 6.2.4. Connection to Modbus FOR MODBUS TCP Connect the Modbus TCP Ethernet cable to the gateway's Ethernet Port. The correct cable to use depends on where the gateway is connected: • Connecting directly to a Modbus TCP device: use a crossover Ethernet UTP/FTP CAT5 or higher cable. •...

  • Page 18: Connection To Knx

    Connection 700series Air Gateway - IN775FGL⁎⁎⁎O000 6.2.5. Connection to KNX Connect the KNX TP communication cable to the gateway's KNX port. IMPORTANT Observe polarity. NOTE See the Wiring diagram (page 11). 6.2.6. Connection to BACnet FOR BACNET/IP Connect the BACnet/IP Ethernet cable to the gateway's Ethernet Port. The correct cable to use depends on where the gateway is connected: •...

  • Page 19: Connection To Home Automation

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Connection IMPORTANT Observe the standard restrictions of the EIA-485 bus: • Maximum distance of 1200 meters (0.75 miles). • Maximum of 32 devices connected to the bus. • A termination resistor of 120 ohms (Ω) is needed at each end of the bus. The gateway has an internal bus biasing circuit incorporating the termination resistor.

  • Page 20: Connection To A Pc For Configuration

    Connection 700series Air Gateway - IN775FGL⁎⁎⁎O000 6.2.8. Connection to a PC for Configuration Use the supplied USB Mini-B type to USB Type-A cable to connect the gateway through its Console port to a PC to configure it with Intesis MAPS. NOTE To know more about the gateway configuration, consult the Intesis MAPS guide for...

  • Page 21: Gateway Layout

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Gateway Layout 6.3. Gateway Layout Figure 6. Disposition of hardware elements in the gateway Plastic covers numbered in the image as ①, ②, ③, and ④ can be easily disassembled. NOTE LEDs and DIP switches are hidden behind the removable plastic covers and can only be accessed by disassembling the covers.

  • Page 22: Led Indicators

    LED Indicators 700series Air Gateway - IN775FGL⁎⁎⁎O000 6.4. LED Indicators Table 1. LEDs location and behavior Cover Color Description Top side LED 1 (PWR) Green Power on (not programmable) LED 2 (ERR) Blinking: Hardware error Under frontal cover ① LED 3 Green 485 Tx (RS485 for BACnet or Modbus) LED 4...

  • Page 23: Dip Switches

    700series Air Gateway - IN775FGL⁎⁎⁎O000 DIP Switches 6.5. DIP Switches The gateway has two DIP switches (see the figure Disposition of hardware elements in the gateway (page 18)): • DIP switch A (SW A) • DIP switch B (SW B) Each DIP switch is dedicated to a 485 port, and its function is to activate or deactivate the termination resistor (position 1) and the polarization (positions 2 and 3) of each port: Position...

  • Page 24: Technical Specifications

    Technical Specifications 700series Air Gateway - IN775FGL⁎⁎⁎O000 6.7. Technical Specifications Plastic, type PC (UL 94 V-0). Color: Light Grey. RAL 7035 Housing Net dimensions (HxWxD): Millimeters: 90 x 106 x 58 mm / Inches: 3.5 x 4.2 x 2.3" Wall: Use M3 25 mm (1") length screws. Secure mounting: below 2 meters (6 feet) Mounting DIN rail (recommended mounting) EN60715 TH35 Wire cross-section/gauge per terminal:...

  • Page 25: Dimensions

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Dimensions 6.8. Dimensions NET DIMENSIONS (HxWxD) Millimeters: 90 x 106 x 58 mm Inches: 3.5 x 4.2 x 2.3" IMPORTANT Leave enough clear space to wire the gateway easily and for the subsequent manipulation of elements.

  • Page 26: Available Protocol Combinations

    Available Protocol Combinations 700series Air Gateway - IN775FGL⁎⁎⁎O000 7. Available Protocol Combinations 7.1. Integration into Modbus Systems 7.1.1. Modbus Registers NOTICE This part is common for Modbus RTU and TCP. Functions to read Modbus registers: • 03 Read Holding Registers. •...
  • Page 27 700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into Modbus Systems Modbus Register name Possible values address Fan Speed Low (all the units) 1: Set Fan Speed Low Fan Speed Med-Low (all the units) 1: Set Fan Speed Med-Low Fan Speed Med-High (all the units) 1: Set Fan Speed Med-High Fan Speed High (all the units) 1: Set Fan Speed High...
  • Page 28 Integration into Modbus Systems 700series Air Gateway - IN775FGL⁎⁎⁎O000 Register name Possible values Modbus address formula 1: Pos1 2: Pos2 (IU address[0..63] + 1) × 100 + Vane Position U-D 3: Pos3 4: Pos4 10-Swing 1: Pos1 2: Pos2 3: Pos3 (IU address[0..63] + 1) ×...
  • Page 29 700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into Modbus Systems Register name Possible values Modbus address formula 0: Allow (IU address[0..63] + 1) × 100 + Allow Setpoint from RC 1: Not allow 0: Thermo Off (IU address[0..63] + 1) × 100 + Thermo Off 1: Thermo On Consumption...

  • Page 30: Integration Into Knx Systems

    Integration into KNX Systems 700series Air Gateway - IN775FGL⁎⁎⁎O000 7.2. Integration into KNX Systems 7.2.1. KNX Signals The following tables list all available KNX signals for this gateway. NOTE Physical Address: The gateway supports (P/S) and (P/I/S) format levels. NOTICE Communication object flags: •...
  • Page 31 700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into KNX Systems Object name Possible values Flags Cool: 19 .. 30°C / 66 .. 86°F Temperature Setpoint (all 9.001-DPT_Value_Temp units) (2byte) Heat: 17 .. 30°C / 63 .. 86°F 0: No disabled Remote control 1.002-DPT_Boolean (1bit) disablement 1: Disabled...
  • Page 32 Integration into KNX Systems 700series Air Gateway - IN775FGL⁎⁎⁎O000 Object name Possible values Flags 0: Auto 1: Heat 20.105- Status_Operation mode 3: Cool DPT_HVACContrMode R, T (1byte) 9: Fan 14: Dry 0: Auto 1: Heat Control_Operation mode 2: Dry 5.x (1byte) 3: Fan 4: Cool 0: Auto...
  • Page 33 700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into KNX Systems Object name Possible values Flags Thresholds: 0 .. 37 % Control_Fan speed scaling 38 .. 62 % 5.001-DPT_Scaling (1byte) 63 .. 87 % 88 .. 100 % Thresholds: 25 % Status_Fan speed scaling 50 % 5.001-DPT_Scaling (1byte) R, T...
  • Page 34 Integration into KNX Systems 700series Air Gateway - IN775FGL⁎⁎⁎O000 Object name Possible values Flags 1: Speed high active Status_Fan speed high 1.001-DPT_Switch (1bit) R, T 0: Speed high not active Control_Fan speed quiet 1: Set fan speed quiet 1.001-DPT_Switch (1bit) 1: Speed quiet active Status_Fan speed quiet 1.001-DPT_Switch (1bit)
  • Page 35 700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into KNX Systems Object name Possible values Flags Thresholds: 0 .. 29 % 30 .. 49 % Control_Vanes L-R scaling 5.001-DPT_Scaling (1byte) 50 .. 69 % 70 .. 89 % 90 .. 100 % Thresholds: 20 % 40 %...
  • Page 36 Integration into KNX Systems 700series Air Gateway - IN775FGL⁎⁎⁎O000 Object name Possible values Flags 0: Normal Status_FilterSign 1.005-DPT_Alarm (1bit) R, T 1: Alarm 0: No reset Control_FilterReset 1.015-DPT_Reset (1bit) 1: Reset 0: No disabled Control_Remote control 1.002 DPT_Bool (1bit) disablement (all) 1: Disabled 0: No disabled Status_Remote control...

  • Page 37: Integration Into Bacnet Systems

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into BACnet Systems 7.3. Integration into BACnet Systems NOTICE You can consult the Protocol Implementation Conformance Statement (PICS) document here. 7.3.1. BACnet Objects NOTICE This part is common for BACnet MS/TP and BACnet/IP. Input object types: •...
  • Page 38 Integration into BACnet Systems 700series Air Gateway - IN775FGL⁎⁎⁎O000 Object Object name Possible values Object type instance 1: No disabled 14-Multistate Batch_RC_Prohibition_C Output 0: Disabled Table 9. Outdoor units signals Object name Possible values Object type Object instance 1: Not set 2: 100% 3: 90% 4: 80%...
  • Page 39 700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into BACnet Systems Object name Possible values Object type Object instance 1: Cool 2: Heat 14-Multistate (U[1..64] × 100 ) + IUXX_OperationMode_C 3: Fan Output 4: Dry 5: Auto 1: Cool 2: Heat 13-Multistate (U[1..64] ×...
  • Page 40 Integration into BACnet Systems 700series Air Gateway - IN775FGL⁎⁎⁎O000 Object name Possible values Object type Object instance 1: Pos1 2: Pos2 3: Pos3 13-Multistate (U[1..64] × 100 ) + IUXX_AirFlowDirHZ_S Input 4: Pos4 5: Pos5 6: Swing 1-Analog (U[1..64] × 100 ) + IUXX_SetTemp_C °C / °F Output...

  • Page 41: Analog Output

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into BACnet Systems Object name Possible values Object type Object instance 1-Analog (U[1..64] × 100 ) + IUXX_HeatTempLoLim_C °C / °F Output (U[1..64] × 100 ) + IUXX_HeatTempLoLim_S °C / °F 0-Analog Input 1-Analog (U[1..64] ×...

  • Page 42: Integration Into Home Automation Systems

    Integration into Home Automation Systems 700series Air Gateway - IN775FGL⁎⁎⁎O000 7.4. Integration into Home Automation Systems 7.4.1. Home Automation Signals The following tables list all available Home Automation signals for this gateway. NOTE • SET: Command used to control the indoor unit. It is sent by the client. •...
  • Page 43 700series Air Gateway - IN775FGL⁎⁎⁎O000 Integration into Home Automation Systems Name Possible values acNum Commands supported Error OU CHN/GET NOTE This index must be set according to the Unit ID Index. For outdoor units, the acNum value must be the same as the minimum indoor unit associated in the CONFIGURATION section.

  • Page 44: Late Configuration: Change The Gateway's Protocol

    Late Configuration: Change the Gateway's Protocol 700series Air Gateway - IN775FGL⁎⁎⁎O000 8. Late Configuration: Change the Gateway's Protocol Reconfiguring the gateway with a different protocol is very easy: Connect the gateway to the PC and open the configuration tool Intesis MAPS. Select the new template you need.

  • Page 45: Error Codes

    700series Air Gateway - IN775FGL⁎⁎⁎O000 Error Codes 9. Error Codes NOTE These error codes are the same for all applications. Modbus/KNX/ BACnet value Home automation Error code Description value Remote controller communication error Communication error between Outdoor unit Network communication error Scan error Peripheral device communication error Electricity charge apportionment error...
  • Page 46 Error Codes 700series Air Gateway - IN775FGL⁎⁎⁎O000 Modbus/KNX/ BACnet value Home automation Error code Description value Heat sink temp. sensor error Sub-cool Heat Ex. gas temp. sensor error Liquid pipe temp. sensor error Current sensor error Pressure sensor error Compressor 2 error Compressor start up error Trip detection Compressor motor control error...
