DALI to Modbus TCP and RTU
Register name
Gyxx_Arc Colour White level for RGBW
For RGBW only
Gyxx_Colour Tc Step Warmer/Cooler
Address formula:
y: Line number (0)
xx: Group number (0 .. 15)
Table 22. Broadcast - Color ballasts (Type 8)
Register name
Arc Colour Level
Arc Colour White Level for RGBW
For RGBW only
Colour Tc Step Warmer/Cooler
Address formula:
y: Line number (0)
Table 23. Energy reporting (Type 51)
Register name
Uyxx_Active Energy
Uyxx_Active Power
Uyxx_Apparent Energy
Optional signal
Uyxx_Apparent Power
Optional signal
Uyxx_Active Energy Loadside
Optional signal
Uyxx_Active Power Loadside
Optional signal
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
Table 24. Diagnostics and maintenance (Type 52)
Register name
Control Gear Operation Time
Control Gear Start Counter
Control Gear Temperature
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
USER MANUAL Version 1.0.2
Possible values
W: 0 .. 100
0: Step Cooler
1: Step Warmer
Possible values
Tc: 1000 .. 10000°K
RGB: 0 .. 251600
W: 0 .. 100
0: Step Cooler
1: Step Warmer
Possible values
0 .. 281474976710653 Wh
0 .. 4294967293 W
0 .. 281474976710653 VAh
0 .. 4294967293 VA
0 .. 281474976710653 Wh
0 .. 4294967293 W
Possible values
0 .. 4294967293 seconds
0 .. 16777213
-60 .. 193°C
Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Address formula R/W
7000*y+(20*xx)+6417 RW
7000*y+(20*xx)+6418 RW
Address formula R/W
7000*y+6815 RW
7000*y+6816 RW
7000*y+6817 RW
Address formula R/W
25000+(3200*y)+(100*xx)+34
25000+(3200*y)+(100*xx)+36
25000+(3200*y)+(100*xx)+38
25000+(3200*y)+(100*xx)+40
25000+(3200*y)+(100*xx)+42
25000+(3200*y)+(100*xx)+44
Address formula
25000+(3200*y)+(100*xx)+46
25000+(3200*y)+(100*xx)+48
25000+(3200*y)+(100*xx)+50
Channel
R
R
R
R
R
R
R/W
R
R
R
