DALI to Modbus TCP and RTU
Table 19. LED ballasts (Type 6)
Register name
Failure Status
Gear Type
Dimming Curve
Possible Operating Modes
Features
Reference Running
Current Protector
Operating Mode
Fast Fade Time
Min Fast Fade Time
Reference System Power
Enable/Disable Current Protector
Select Dimming Curve
Store Fast Fade Time
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
USER MANUAL Version 1.0.2
Possible values
b7: RefMeasurFail
b6: ThermLightLvl
b5: ThermShut
b4: CurrProtAct
b3: LoadInc
b2: LoadDec
b1: OpenC
b0: ShortC
b3: dcSuppPoss
b2: acSuppPoss
b1: LEDModInt
b0: LEDPowerSInt
0: Standard Logarithmic Dim Curve
1: Linear Dim Curve
b3: HighCurrPulMod
b2: OutCurrContr
b1: AMModePoss
b0: PWMModePoss
b7: PhysicSelSupp
b6: LightLvlRedReq
b5: ThermShutReq
b4: CurrProtActReq
b3: LoadIncReq
b2: LoadDecReq
b1: OpenCQ
b0: ShortCQ
0: No
1: Yes
0: Disabled
1: Enabled
b4: NonLogDimCurveAct
b3: HighCurrPulModeAct
b2: OutCurrContr
b1: AMModeAct
b0: PWMModeAct
0 .. 27
0 .. 27
1: Trigger DALI Power Referencing
0: Disable
1: Enable
0: Standard Logarithmic Dim Curve
1: Linear Dim Curve
0 .. 27
Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Address formula R/W
7000*y+(100*xx)+80 R
7000*y+(100*xx)+81 R
7000*y+(100*xx)+82 R
7000*y+(100*xx)+83 R
7000*y+(100*xx)+84 R
7000*y+(100*xx)+85 R
7000*y+(100*xx)+86 R
7000*y+(100*xx)+87 R
7000*y+(100*xx)+88 R
7000*y+(100*xx)+89 R
7000*y+(100*xx)+90 W (T)
7000*y+(100*xx)+91 RW
7000*y+(100*xx)+92 RW
7000*y+(100*xx)+93 RW
Channel
