Dip Switches; Buttons - HMS Networks Intesis IN703DAL0640000 User Manual

Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Channel
LED
Run
Error
Eth. Link
Eth. Spd
TX blinking green
Port A TX/RX
RX blinking yellow
TX blinking green
Port B TX/RX
RX blinking yellow
LED for Button A
LED for Button B
For the DALI-2 to
BACnet application only

5.4. DIP Switches

The gateway has two DIP switches:
• DIP switch A (SW A)
• DIP switch B (SW B)
Each DIP switch is dedicated to a 485 port, and its function is to activate or deactivate the termination resistor
and the polarization of each port:
Position
1 2 3
↑ X X 120 Ω termination active
↓ X X 120 Ω termination inactive (default position)
X ↑ ↑ Polarization active (default position)
X ↓ ↓ Polarization inactive

5.5. Buttons

Button A
Press the button once to broadcast a RECALL_MAX_LEVEL for 30 seconds. Press the button again to broadcast an
OFF.
Page 16 of 40
Color Description
Off No power
The gateway is
Green
connected and running
Off No error
Red Error
Off No connection
Green Connection established
Off No transmission
Yellow Transmitting data
Off No activity
Data packet
transmitted to the DALI
network
Data packet received
from the DALI network
Off No activity
Data packet
transmitted to the
BACnet or Modbus
network
Data packet received
from the BACnet or
Modbus network
This LED turns to
steady red for 30
Red
seconds when you
press Button A
Link with BACnet/IP
Green
established
Button B has been
Off
pressed
Description
DIP Switches
USER MANUAL Version 1.0.2
