DALI to Modbus TCP and RTU
Register name
Broadcast Multicontrol
Address formula:
y: Line number (0)
Table 18. Emergency ballasts (Type 1)
Register name
Failure Status
Emergency Mode
Emergency Status
Emergency Battery Charge
Next Function Test
Next Duration Test
Function Test Interval
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
USER MANUAL Version 1.0.2
Possible values
0: Off
1: 100%
2: StpUp
3: StpDwn
1XX: GoScn
2XX: StoreScn
3XX: RmvScn
1XXX: FdRate
2XXX: FdTime
3XXX: MinLvl
4XXX: MaxLvl
5XXX: PwrOnLvl
6XXX: SysFailLvl
Possible values
b7: FunctFail
b6: DurFail
b5: DurTestDelay
b4: FunctTestDelay
b3: EmLampFail
b2: BattFail
b1: BattDurFail
b0: CircFail
b7: HardSwOn
b6: HardInhibit
b5: DurTestProg
b4: FunctTestProg
b3: ExtdEmMode
b2: EmMode
b1: NormMode
b0: RestMode
b7: PhysicSel
b6: Ident
b5: DurTestPend
b4: FunctTestPend
b3: BattFull
b2: DurTestDone
b1: FunctTestDone
b0: InhibitMode
0 .. 100%
0 .. 16384 hours
0 .. 16384 hours
0: Disabled
1 .. 255 days
Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Address formula R/W
7000*y+6814 RW
Address formula R/W
7000*y+(100*xx)+42 R
7000*y+(100*xx)+43 R
7000*y+(100*xx)+44 R
7000*y+(100*xx)+45 R
7000*y+(100*xx)+46 R
7000*y+(100*xx)+47 R
7000*y+(100*xx)+48 R
Channel
