Buttons
NOTE
When having a pen drive connected to the gateway's USB connector, press button A to save the
project or/and the logs to the pen drive.
This behavior can be configured through Intesis MAPS. To know more, see the
manual for IN703DAL0640000.
Button B
Press the button once to send an I-Am message to the network.
NOTICE
This function for button B only applies to the DALI to BACnet application.
NOTE
When having a pen drive connected to the gateway's USB connector, press button B to download a
project or/and a firmware version from the pen drive to the gateway.
The gateway will download the last saved project. The project/firmware must be located in the pen
drive root memory, not inside a folder. This function of button B works for BACnet and Modbus.
This behavior can be configured through Intesis MAPS. To know more, see the
manual for IN703DAL0640000.
Button A + button B
Follow this procedure to reset the gateway to the factory settings:
1. Reboot the gateway.
NOTE
To reboot the gateway, disconnect it from the power supply and connect it again.
2. Keep both buttons pressed simultaneously while rebooting the gateway.
3. After 5-10 seconds, all LEDs will light up and out in a cycle from top to bottom.
4. Release the buttons.
5. The LEDs cycle can take up to 90 seconds until the process finishes.
