DALI to Modbus TCP and RTU
Register name
Multicontrol
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
Table 16. DALI groups - All ballasts
Register name
Arc Power Level
Arc Power Off / On
Step Down / Up
Recall Min Level
Recall Max Level
Go to Scene
Store Current Level as Scene
Clear/Remove Scene
Set Fade Time
Set Fade Rate
Set Min Level
Set Max Level
Set Power-on Level
Set System-failure Level
Address formula:
y: Line number (0)
xx: Group number (0 .. 15)
USER MANUAL Version 1.0.2
Possible values
0: Off
1: 100%
2: StpUp
3: StpDwn
1XX: GoScn
2XX: StoreScn
3XX: RmvScn
1XXX: FdRate
2XXX: FdTime
3XXX: MinLvl
4XXX: MaxLvl
5XXX: PwrOnLvl
6XXX: SysFailLvl
Possible values
0 .. 100% 7000*y+(20*xx)+6400
0: Off
7000*y+(20*xx)+6401
1: 100%
0: Step Down
7000*y+(20*xx)+6402
1: Step Up
1: Recall Min Level 7000*y+(20*xx)+6403
1: Recall Max Level 7000*y+(20*xx)+6404
0 .. 15 7000*y+(20*xx)+6405
0 .. 15 7000*y+(20*xx)+6406
0 .. 15 7000*y+(20*xx)+6407
0 .. 15 7000*y+(20*xx)+6408
1 .. 15 7000*y+(20*xx)+6409
0 .. 100% 7000*y+(20*xx)+6410
0 .. 100% 7000*y+(20*xx)+6411
0 .. 100% 7000*y+(20*xx)+6412
0 .. 100% 7000*y+(20*xx)+6413
Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Address formula R/W
7000*y+(100*xx)+31 RW
Address formula R/W
RW
RW
RW
W (T)
W (T)
RW
RW
RW
RW
RW
RW
RW
RW
RW
Channel
