HMS Networks Intesis IN703DAL0640000 User Manual page 37

Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Channel
Register name
Duration Test Interval
Test Execution Timeout
Prolong Time
Duration Test Result
Lamp Total Operation Time
Emergency Level
Emergency Min Level
Emergency Max Level
Rated Duration
Features
Lamp Emergency Time
Rest
Inhibit
Re-Light/Reset Inhibit
Start Function Test
Start Duration Test
Stop Test
Reset Function Test Done Flag
Reset Duration Test Done Flag
Reset Lamp Time
Store Test Execution Timeout
Store Prolong Time
Store Function Test Interval
Store Duration Test Interval
Store Emergency Level
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
Page 34 of 40
Possible values
0: Disabled
1 .. 97 weeks
0 .. 255 days
0 .. 127.5 minutes
0 .. 510 minutes
0 .. 1016 hours
0 .. 100%
0 .. 100%
0 .. 100%
0 .. 510 minutes
b7: RelightRestSup
b6: PhysicSelSup
b5: HardInSup
b4: AdjsEmLvl
b3: AutoTestCap
b2: SwitchMainCG
b1: MainCG
b0: IntegralEmCG
0 .. 254 hours
1: Extinguish Lamp
1: Start Inhibit Mode
1: Cancel Inhibit Mode
1: Start Function Test
1: Start Duration Test
1: Stop Function/Duration Test
1: Reset Function Flag
1: Reset Duration Flag
1: Lamp Emergency Time Reset
0 .. 255 days
0 .. 127.5 minutes
0: Disabled
1 .. 255 days
0: Disabled
1 .. 97 weeks
0 .. 100%
DALI to Modbus TCP and RTU
Address formula R/W
7000*y+(100*xx)+49 R
7000*y+(100*xx)+50 R
7000*y+(100*xx)+51 R
7000*y+(100*xx)+52 R
7000*y+(100*xx)+53 R
7000*y+(100*xx)+54 R
7000*y+(100*xx)+55 R
7000*y+(100*xx)+56 R
7000*y+(100*xx)+57 R
7000*y+(100*xx)+58 R
7000*y+(100*xx)+59 R
7000*y+(100*xx)+60 W (T)
7000*y+(100*xx)+61 W (T)
7000*y+(100*xx)+62 W (T)
7000*y+(100*xx)+63 W (T)
7000*y+(100*xx)+64 W (T)
7000*y+(100*xx)+65 W (T)
7000*y+(100*xx)+66 W (T)
7000*y+(100*xx)+67 W (T)
7000*y+(100*xx)+68 W (T)
7000*y+(100*xx)+69 RW
7000*y+(100*xx)+70 RW
7000*y+(100*xx)+71 RW
7000*y+(100*xx)+72 RW
7000*y+(100*xx)+73 RW
USER MANUAL Version 1.0.2
