DALI to BACnet/IP and MS/TP
Table 8. Color control (Type 8)
Object name
Uyxx_Store Current Level & Colour
as Scene
Uyxx_Clear/Remove Colour from
Scene
Uyxx_Arc Colour Level
Uyxx_Arc Colour White Level-
RGBW
For RGBW only
Uyxx_Colour Tc Step W/C
Uyxx_Actual Colour Level
Uyxx_Actual Colour White Level-
RBGW
For RGBW only
Uyxx_Power ON Colour
Uyxx_Power ON Colour White
Level-RGBW
Uyxx_System Fail Colour
Uyxx_Syst Fail Colour White Level-
RGBW
Uyxx_Min Colour Range (°K)
Uyxx_Max Colour Range (°K)
Uyxx_Set Power ON Colour
Uyxx_Set Power ON Colour White
Level-RGBW
Uyxx_Set System Fail Colour
Uyxx_Set Syst Fail Colour White
Level-RGBW
Uyxx_Set Min Colour Range (°K)
Uyxx_Set Max Colour Range (°K)
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
Table 9. DALI groups - Color ballasts (Type 8)
Object name
Gyxx_Arc Colour level
Gyxx_Arc Colour White level for RGBW
For RGBW only
Gyxx_Colour Tc Step Warmer/Cooler
Address formula:
y: Line channel (0)
xx: Group number (0 .. 15)
USER MANUAL Version 1.0.2
Possible values Object type
0 .. 15 1-Analog Output
0 .. 15 1-Analog Output
Tc: 1000 .. 10000°K
1-Analog Output
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 1-Analog Output
0: Step Cooler
4-Binary Output
1: Step Warmer
Tc: 1000 .. 10000°K
0-Analog Input
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 0-Analog Input
Tc: 1000 .. 10000°K
0-Analog Input
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 0-Analog Input
Tc: 1000 .. 10000°K
0-Analog Input
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 0-Analog Input
Tc: 1000 ... 10000°K 0-Analog Input
Tc: 1000 .. 10000°K 0-Analog Input
Tc: 1000 .. 10000°K
1-Analog Output
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 1-Analog Output
Tc: 1000 .. 10000°K
1-Analog Output
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 1-Analog Output
Tc: 1000 .. 10000°K 1-Analog Output
Tc: 1000 .. 10000°K 1-Analog Output
Possible values Object type
Tc: 1000 .. 10000°K
1-Analog Output
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 1-Analog Output
0: Step Cooler
4-Binary Output
1: Step Warmer
Intesis DALI-2 Protocol Translator with Serial and IP Support - 1 DALI
Object instance R/W
25000+(3200*y)+(50*xx)+0 W
25000+(3200*y)+(50*xx)+1 W
25000+(3200*y)+(50*xx)+2 W
25000+(3200*y)+(50*xx)+3 W
25000+(3200*y)+(50*xx)+0 W
25000+(3200*y)+(50*xx)+0 R
25000+(3200*y)+(50*xx)+1 R
25000+(3200*y)+(50*xx)+2 R
25000+(3200*y)+(50*xx)+3 R
25000+(3200*y)+(50*xx)+4 R
25000+(3200*y)+(50*xx)+5 R
25000+(3200*y)+(50*xx)+6 R
25000+(3200*y)+(50*xx)+7 R
25000+(3200*y)+(50*xx)+4 W
25000+(3200*y)+(50*xx)+5 W
25000+(3200*y)+(50*xx)+6 W
25000+(3200*y)+(50*xx)+7 W
25000+(3200*y)+(50*xx)+8 W
25000+(3200*y)+(50*xx)+9 W
Object instance R/W
7000*y+(20*xx)+6410 RW
7000*y+(20*xx)+6411 RW
7000*y+(20*xx)+6404 RW
Channel
