Table 10. Broadcast - Color ballasts (Type 8)
Object name
By_Arc Colour level
By_Arc Colour White level for RGBW
For RGBW only
By_Colour Tc Step Warmer/Cooler
Address formula:
y: Line channel (0)
Table 11. Energy reporting (Type 51)
Object name Possible values
Uyxx_Active Energy 0 .. 281474976710653 Wh
Uyxx_Active Power 0 .. 4294967293 W
Uyxx_Apparent Energy
0 .. 281474976710653 VAh
Optional signal
Uyxx_Apparent Power
0 .. 4294967293 VA
Optional signal
Uyxx_Active Energy Loadside
0 .. 281474976710653 Wh
Optional signal
Uyxx_Active Power Loadside
0 .. 4294967293 W
Optional signal
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
Table 12. Diagnostics and maintenance (Type 52)
Object name Possible values
Uyxx_Control Gear
0 .. 4294967293 seconds
Operating Time
Uyxx_Control Gear Start
0 .. 16777213
Counter
Uyxx_Control Gear
-60 .. 193°C
Temperature
bitfields
0: Overal failure
1: Ext. Supply Undervoltage
Uyxx_Control Gear Failure 2: Ext. Supply Overvoltage
3: ECG Output Power Limit
4: Thermal derating
5: Thermal shutdown
Uyxx_Light Source Start
0 .. 16777213
Counter Resettable
Uyxx_Light Source Set Start
0 .. 16777213
Counter Resettable
Uyxx_Light Source Start
0 .. 16777213
Counter
Address formula:
y: Channel number (0)
xx: Ballast short address (0 .. 63)
Page 26 of 40
Possible values Object type
Tc: 1000 .. 10000°K
1-Analog Output
RGB: 0 .. 0xFEFEFE
W: 0 .. 100 1-Analog Output
0: Step Cooler
4-Binary Output
1: Step Warmer
Object type
0-Analog Input
0-Analog Input
0-Analog Input
0-Analog Input
0-Analog Input
0-Analog Input
Object type
0-Analog Input
0-Analog Input
0-Analog Input
0-Analog Input
1-Analog Input
1-Analog Output
1-Analog Input
Object instance R/W
7000*y+6810 RW
7000*y+6811 RW
7000*y+6804 RW
Object instance R/W
25000+(3200*y)+(50*xx)+8 R
25000+(3200*y)+(50*xx)+9 R
25000+(3200*y)+(50*xx)
R
+10
25000+(3200*y)+(50*xx)
R
+11
25000+(3200*y)+(50*xx)
R
+12
25000+(3200*y)+(50*xx)
R
+13
Object instance R/W
25000+(3200*y)+(50*xx)
R
+14
25000+(3200*y)+(50*xx)
R
+15
25000+(3200*y)+(50*xx)
R
+16
25000+(3200*y)+(50*xx)
R
+17
25000+(3200*y)+(50*xx)
RW
+10
25000+(3200*y)+(50*xx)
RW
+11
25000+(3200*y)+(50*xx)
RW
+12
