Register name
Multicontrol
Daylight Active-single Group
Address formula:
y: Line number (0)
xx: Group number (0 .. 15)
Table 17. Broadcast - All ballasts
Register name
Arc Power Level
Arc Power Off / On
Step Down / Up
Recall Min Level
Recall Max Level
Go to Scene
Store Current Level as Scene
Clear/Remove Scene
Set Fade Time
Set Fade Rate
Set Min Level
Set Max Level
Set Power_on Level
Set System-failure Level
Address formula:
y: Line number (0)
Page 32 of 40
Possible values
0: Off
1: 100%
2: StpUp
3: StpDwn
1XX: GoScn
2XX: StoreScn
3XX: RmvScn 7000*y+(20*xx)+6414
1XXX: FdRate
2XXX: FdTime
3XXX: MinLvl
4XXX: MaxLvl
5XXX: PwrOnLvl
6XXX: SysFailLvl
0: Inactive
7000*y+(20*xx)+6415
1: Active
Possible values
0 .. 100%
0: Off
1: 100%
0: Step Down
1: Step Up
1: Recall Min Level
1: Recall Max Level
0 .. 15
0 .. 15
0 .. 15
0 .. 15
1 .. 15
0 .. 100%
0 .. 100%
0 .. 100%
0 .. 100%
Address formula R/W
RW
R
Address formula R/W
7000*y+6800 RW
7000*y+6801 RW
7000*y+6802 RW
7000*y+6803 W (T)
7000*y+6804 W (T)
7000*y+6805 RW
7000*y+6806 RW
7000*y+6807 RW
7000*y+6808 RW
7000*y+6809 RW
7000*y+6810 RW
7000*y+6811 RW
7000*y+6812 RW
7000*y+6813 RW
