Appendix B: System Specifications
Appendix B
System Specifications
Processors
Supports a single Intel Xeon E-2400 processor, in Socket V0 (LGA 1700) with up to eight cores
Chipset
Intel C266
BIOS
AMI 256 MB AMI BIOS SPI Flash BIOS
Memory
Up to 128 GB of DDR5 ECC UDIMM memory with speeds of up to 4400 MT/s in four memory slots
Storage Drives
Fixed internal SATA drives: two 3.5" drives or three 2.5" drives
Two M.2 PCIe 4.0 x4 M-Key NVMe
PCI Expansion Slots
One PCIe 5.0 x16, FHHL
Input/Output
LANs: Two 1 G Base-T ports; one dedicated port for BMC
USB: five USB 3.2 Gen 1 ports (2 rear, 2 headers, 1 Type A)
Six USB 2.0 ports (2 rear, 4 headers)
VGA, two Serial (1 rear, 1 header)
(Optional) DVD drive
Motherboard
X13SCH-SYS, 9.6" x 9.6" Micro ATX (243.84 mm x 243.84 mm)
Chassis
CSE-512F-350B1; 1U Rackmount, 17.2 x 1.7 x 14.5 in. (437 x 43 x 368 mm) (WxHxD)
System Cooling
Two 4-cm counter-rotating fans with speed control
CPU heatsink and air shroud to direct air flow
Power Supply
PWS-350-1H, 350 W 80Plus Platinum level
Output
+12 V, 350 W 29 A
+5 V, 15 A
+3.3 V, 12 A
5 V standby, 3 A
Operating Environment
Operating Temperature: 10º to 35º C (50º to 95º F)
Non-operating Temperature: -30º to 60º C (-22º to 140º F)
Operating Relative Humidity: 8% to 80% (non-condensing)
Non-operating Relative Humidity: 8% to 90% (non-condensing)
