SuperServer
®
SYS-521R-T
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SuperServer SYS-521R-T

Summary of Contents for Supermicro SuperServer SYS-521R-T

  • Page 1 SuperServer ® SYS-521R-T USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Contacting Supermicro ......................7 Chapter 1 Introduction 1.1 Overview ..........................8 1.2 System Features ........................9 System: Front View ......................9 Control Panel ........................10 System: Rear View ......................11 1.3 Motherboard Layout ......................12 Quick Reference Table ......................13 Block Diagram ........................14 Chapter 2 Maintenance and Component Installation 2.1 Removing Power ........................15...
  • Page 5 Preface Front-Mounted Hot-Swap Drives ..................27 Installing the Internal Fixed Drives ..................29 Adding an M.2 Storage Card ....................31 Installing a Fan ........................32 Replacing the Power Supply .....................33 Chapter 3 Motherboard Connections 3.1 Power Connections ......................34 3.2 Headers and Connectors ....................35 Front Control Panel ......................37 3.3 Rear I/O Ports ........................40 3.4 Jumper Settings .........................43 How Jumpers Work ......................43...
  • Page 6 6.7 Where to Get Replacement Components ................65 6.8 Reporting an Issue ......................65 Technical Support Procedures ..................65 Returning Merchandise for Service ...................65 Vendor Support Filing System ..................66 6.9 Feedback ..........................66 6.10 Contacting Supermicro ......................67 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications...

  • Page 7: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Chapter 1 Introduction

    Compact Mini-Tower, 9.45 x 8.27 x 11 in. / 240 x 210 x 279 mm (H x W x D) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the SYS-521R-T have been certified as compliant...

  • Page 9: System Features

    Chapter 1: Introduction 1.2 System Features System: Front View The CSE-721TQ is a compact mini-tower chassis. Refer to Appendix B for additional specifications. The chassis front offers access to the storage drives, a control panel for each node, four pullout service tags, and two thumbscrews. Fixed Drive Area Control Panel USB Ports...

  • Page 10: Control Panel

    Chapter 1: Introduction Control Panel Power switches and status LEDs are located on the control panel on the front of the chassis. Power LED Power Button Drive Activity LED NIC LED Reset Button Information LED Figure 1-2. Control Panel Control Panel Features Feature Description The main power button applies or removes primary power from the power supply to the...

  • Page 11: System: Rear View

    Chapter 1: Introduction System: Rear View The illustration below shows the rear view of the chassis. The various I/O ports are located below the power supply. Power Supply IPMI LAN USB 2.0 USB 3.2 Figure 1-3. System Rear View Rear Chassis Features Feature Description Power Supply...

  • Page 12: Motherboard Layout

    Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the X13SCL-iF with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter LED1 BMC_LAN LED2...

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) Pins 1–2 (4x SATA) JNS1 SATA 3.0 or PCIe 4.0 Selection Pins 2–3 (PCIe x4) JPG1 VGA Enable/Disable Pins 1–2 (Enabled) JPL1 LAN1 Enable/Disable Pins 1–2 (Enabled) JPL2 LAN2 Enable/Disable Pins 1–2 (Enabled)

  • Page 14: Block Diagram

    Chapter 1: Introduction Connector Description USB0/1 Back Panel USB 2.0 Ports USB2/3 Back Panel USB 3.2 Gen 1 Ports USB4/5 Front Panel 3.2 Gen 1 Header VGA Port Block Diagram 4800 MT/s support is limited to 1R1R configurations. (64 GB) Up to 128 GB ECC UDIMM (2933 MT/s) DDR5 (CHA) INTEL LGA1700...

  • Page 15: Chapter 2 Maintenance And Component Installation

    Chapter 2: Maintenance and Component Installation Chapter 2 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components requires that power first be removed from the system.

  • Page 16: Rear Chassis Hasp

    Chapter 2: Maintenance and Component Installation Figure 2-1. Front Bezel Lock Rear Chassis Hasp Unauthorized entry through the rear of the chassis may be discouraged by placing a lock on the rear of the chassis. The chassis is equipped with a rear chassis hasp that can accommodate a variety of commonly available locks (not included).

  • Page 17: Accessing The System

    Chapter 2: Maintenance and Component Installation 2.3 Accessing the System The CSE-721TQ-350B2 features a removable top cover to access to the inside of the chassis. Figure 2-4. Removing the Chassis Cover Removing the Top Cover 1. Power down the system as described in section 2.1. 2.

  • Page 18: Motherboard Components

    If you buy a CPU separately, make sure that you use an Intel-certified multi-directional heatsink only. • Refer to the Supermicro website for updates on processor support. • All graphics in this manual are for illustrations only. Your components may look different.
  • Page 19 Chapter 2: Maintenance and Component Installation 1. Remove the plastic protective cover from the load plate. 2. Gently push down the load lever to release and lift it, then lift the load plate to open it completely. Lever lock 3. Use your thumb and your index finger to hold the CPU. Align the small triangle maker and notches on the CPU to the corresponding triangle maker and notches on the CPU load bracket.
  • Page 20 Chapter 2: Maintenance and Component Installation 5. With the CPU inside the socket, inspect all the corners to make sure it is properly installed. 6. Close the load plate with the CPU inside the socket. Gently push the load lever down until it locks under the Lever Lock latch.

  • Page 21: Heatsink

    Chapter 2: Maintenance and Component Installation Heatsink Installing the CPU Heatsink Do not apply thermal grease to the heatsink or the CPU; the required amount has already been applied. Use an Intel-certified multi-directional heatsink. 1. Power down the system as described in Section 2.1 and remove the chassis cover. 2.

  • Page 22: Memory Support And Installation

    Chapter 2: Maintenance and Component Installation Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X13SCL-iF motherboard supports up to 64 GB of DDR5 ECC UDIMM memory with speeds of up to up to 4800 MT/s (with the one or two DIMM(s) per channel configurations) in two memory slots.

  • Page 23: Dimm Installation

    Chapter 2: Maintenance and Component Installation DIMM Installation 1. Insert DIMM modules in the following order: DIMMA1 and DIMMB1. For the system to work properly, use memory modules of the same type and speed. Receptive Point 2. Align the DIMM module key with the Notch receptive point on the single-latch DIMM slot.

  • Page 24: Battery Removal And Installation

    Chapter 2: Maintenance and Component Installation Battery Removal and Installation The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Battery Removal To remove the onboard battery, follow the steps below: 1.

  • Page 25: Chassis Components

    Chapter 2: Maintenance and Component Installation 2.5 Chassis Components Installing Expansion Cards The SYS-521R-T includes a PCIe 5.0 x16 slot to support one low-profile expansion card. The card is installed by removing the chassis tray that holds the motherboard and the rear I/O shield.
  • Page 26 Chapter 2: Maintenance and Component Installation 4. Remove the screw that secures the PCI slot shield in the PCI slot at the rear of the tray and set it aside for later use. 5. Slide the PCI slot shield up and out of the PCI slot. 6.

  • Page 27: Front-Mounted Hot-Swap Drives

    Chapter 2: Maintenance and Component Installation Front-Mounted Hot-Swap Drives The CSE-721TQ-350B2 supports four hot-swap drives mounted in carriers that are accessible from the front of the chassis. These drives may be removed and installed without powering down the system. Removing 3.5" Hot-Swap Drives 1.
  • Page 28 Chapter 2: Maintenance and Component Installation Drive Dummy Drive Drive Carrier Figure 2-10. Installing a Drive into a Drive Carrier Installing a Drive Carrier into the Drive Cage 1. Insert the drive carrier into the drive bay, using the drive carrier handle to push it all the way into the drive cage until it stops.

  • Page 29: Installing The Internal Fixed Drives

    Chapter 2: Maintenance and Component Installation Installing the Internal Fixed Drives The CSE-721TQ-350B2 chassis supports two internal 2.5" fixed drives (one top-mounted drive and one side-mounted drive) and one DVD-ROM drive. Installing a Top-Mounted Fixed Drive 1. Power down the system as described in Section 2.1 and remove the chassis cover. 2.
  • Page 30 Chapter 2: Maintenance and Component Installation Installing a Side-Mounted Fixed Drive 1. Power down the system as described in Section 2.1 and remove the chassis cover as described in Section 2.3. 2. Place a 2.5" drive into the drive bracket and secure the drive to the bracket with the four screws provided.

  • Page 31: Adding An M.2 Storage Card

    Chapter 2: Maintenance and Component Installation Adding an M.2 Storage Card One M.2 SSD card (M-Key, 2280 form factor) may be installed on the motherboard. 1. Remove power from the system as described in Section 2.1 and remove the chassis cover.

  • Page 32: Installing A Fan

    Chapter 2: Maintenance and Component Installation Installing a Fan The chassis includes a single 12-cm rear exhaust fan. The chassis also features a set of mounting holes that will support a standard 9-cm exhaust fan (not included). Installing the Exhaust Fan 1.

  • Page 33: Replacing The Power Supply

    Chapter 2: Maintenance and Component Installation Replacing the Power Supply The CSE-721TQ-350B2 includes a single (non-hot-swap) 350W power supply. If it is necessary to replace the power supply, follow the instructions below. Changing the Power Supply 1. Power down the system as described in Section 2.1 and remove the chassis cover. 2.

  • Page 34: Chapter 3 Motherboard Connections

    Chapter 3: Motherboard Connections Chapter 3 Motherboard Connections 3.1 Power Connections ATX Power Supply Connector The primary 24-pin power supply connector (JPW1) meets the ATX SSI EPS 12V specification. The 4-pin (JPW2) processor power connector must also be connected to your power supply. 4-pin Power ATX Power 24-pin Connector Pin Definitions...

  • Page 35: Headers And Connectors

    Chapter 3: Motherboard Connections 3.2 Headers and Connectors Chassis Intrusion A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable from the chassis to be informed of a chassis intrusion when the chassis is opened. Refer to the table below for pin definitions.
  • Page 36 Chapter 3: Motherboard Connections SATA 3.0 Ports This motherboard has two SATA 3.0 ports. I-SATA4/5 can be used with Supermicro SuperDOMs that are yellow SATA DOM connectors with power pins built in and do not require external power cables. Supermicro SuperDOMs are backwards compatible with regular SATA HDDs or SATA DOMs that need external power cables.

  • Page 37: Front Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 38 Chapter 3: Motherboard Connections Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both pins will power on/off the system. This button can also be configured to function as a suspend button (with a setting in the BIOS). To turn off the power when the system is in suspend mode, press the button for four seconds or longer.
  • Page 39 Chapter 3: Motherboard Connections NIC1/NIC2 (LAN1/LAN2) The NIC (Network Interface Controller) LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and LAN port 2 is on pins 9 and 10. Attach the NIC LED cables here to display network activity.

  • Page 40: Rear I/O Ports

    Chapter 3: Motherboard Connections 3.3 Rear I/O Ports See Figure 3-2 below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 3-2. I/O Port Locations and Definitions Rear I/O Ports Description Description COM1 USB2 BMC LAN Port...
  • Page 41 Chapter 3: Motherboard Connections LAN Ports Two Gigabit Ethernet ports (LAN1/2) are located on the I/O back panel. In addition to the LAN ports, a dedicated BMC LAN on the back panel. All of these ports accept RJ45 cables. Refer to the LED Indicator section for LAN LED information. LAN Port BMC LAN Pin Definition...
  • Page 42 LED indicator. Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, refer to the IPMI User's Guide posted on our website: https://www.supermicro.com/support/ manuals/ Function User Input...

  • Page 43: Jumper Settings

    Chapter 3: Motherboard Connections 3.4 Jumper Settings How Jumpers Work To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. See the diagram below for an example of jumping pins 1 and 2.
  • Page 44 Chapter 3: Motherboard Connections CPU PCIe Bifurcation Set the JRF1 jumper to set the PCIe lanes to either x16 or two x8 for Slot 7. PCIe Bifurcation Jumper Settings Jumper Setting Definition Pins 1–2 Pins 2–3 Two x8 LAN1 Enable/Disable Use jumper JPL1 to enable or disable LAN port 1 and jumper JPL2 to enable or disable LAN port 2.

  • Page 45: Led Indicators

    Chapter 3: Motherboard Connections VGA Enable/Disable JPG1 allows you to enable or disable the VGA port using the onboard graphics controller. VGA Enable/Disable Jumper Settings Jumper Setting Definition Pins 1–2 Enabled Pins 2–3 Disabled Watch Dog Timer Watch Dog (JWD1) is a system monitor that can reboot the system when a software application hangs.
  • Page 46 Chapter 3: Motherboard Connections LAN LEDs Two LAN ports (LAN1/2) are located on the I/O back panel. Each LAN port has two LEDs. The green LED indicates activity, while the other Link LED may be yellow, amber, or off to indicate the speed of the connection.

  • Page 47: Chapter 4 Software

    1. Create a method to access the Microsoft Windows installation ISO file. That can be a USB flash or media drive. 2. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash or media drive.
  • Page 48 Chapter 4: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 4-2.

  • Page 49: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash or media drive.

  • Page 50: Superdoctor ® 5

    4.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 51: Ipmi

    BIOS settings that are related to IPMI. For general documentation and information on IPMI, visit our website at: http://www.supermicro.com/products/nfo/IPMI.cfm. BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 52: Chapter 5 Optional Components

    Chapter 5: Optional Components Chapter 5 Optional Components This chapter describes optional system components and installation procedures. 5.1 Optional Parts List Optional Parts List Description Part Number Quantity (Max.) Slimline x4 to PCIe SFF-8639 (cable) CBL-SAST-1240A-85 2U Active CPU Heatsink for Intel Socket LGA-1700 SNK-P0092AP4 Black Gen-5.5 tool-less 3.5-to-2.5 drive tray converter MCP-220-00118-0B...

  • Page 53: Chapter 6 Troubleshooting And Support

    Chapter 6 Troubleshooting and Support 6.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Products Figure 6-1. Supermicro Website • Specifications for servers and other hardware are available by clicking the menu icon, then selecting the Products option.

  • Page 54: Baseboard Management Controller Interface

    Security Center for recent security notices Supermicro Phone and Addresses 6.2 Baseboard Management Controller Interface The system supports the Baseboard Management interface. BMC is used to provide remote access, monitoring and management. There are several BIOS settings that are related to BMC.

  • Page 55: Troubleshooting Procedures

    Chapter 6: Troubleshooting and Support 6.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service section(s) in this chapter. Power down the system before changing any non hot-swap hardware components.

  • Page 56: No Video

    Chapter 6: Troubleshooting and Support No Video If the power is on but you have no video, remove all the add-on cards and cables. Then power up the system again to see if you then have video. System Boot Failure If the system does not display POST (Power-On-Self-Test) or does not respond after the power is turned on, check the following: Turn on the system with only one DIMM module installed.
  • Page 57 Chapter 6: Troubleshooting and Support Note: Refer to the product page on our website at http://www.supermicro.com for memory and CPU support and updates. 3. Storage drive support: Make sure that all storage drives work properly. Replace the bad drives with good ones.

  • Page 58: Crash Dump Using Bmc

    Chapter 6: Troubleshooting and Support 6.4 Crash Dump Using BMC In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using BMC.

  • Page 59: Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 60 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 61 Chapter 6: Troubleshooting and Support Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
  • Page 62 Chapter 6: Troubleshooting and Support 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell]. Press <F4>...
  • Page 63 Chapter 6: Troubleshooting and Support Note: Do not interrupt this process until the BIOS flashing is complete. 9. The screen above indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system.

  • Page 64: Cmos Clear

    Chapter 6: Troubleshooting and Support 6.6 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1.

  • Page 65: Where To Get Replacement Components

    6.7 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com.

  • Page 66: Vendor Support Filing System

    For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 6.9 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. Please email us at techwriterteam@supermicro.com to provide feedback on our manuals.

  • Page 67: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 68: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 69 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 70 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 71 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 72 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 73 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components (except for hot-swap components). 電源切断の警告...
  • Page 74 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 75 Appendix A: Warning Statements Attention Seul le personnel autorisé et le personnel de maintenance qualifié doivent être autorisés à installer, remplacer ou entretenir cet équipement.. !‫אזהרה‬ ‫.יש לאפשר רק צוות מורשה ואנשי שירות מוסמכים להתקין, להחליף או לטפל בציוד זה‬ ‫.ينبغي...
  • Page 76 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 77 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 78 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 79 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 80 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 81 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 82 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 83 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 84 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 85 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 86 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 87 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 88: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processor Support Single Intel Xeon E-2400 and 12th Generation Pentium (V0 - LGA1700) processor with up to eight cores Chipset Intel C262 PCH BIOS 256Mb SPI AMI BIOS ® Memory Up to 64 GB of DDR5 ECC UDIMM memory with speeds of up to 4800 MT/s in two DIMM slots Storage Drives Four front hot-swappable 3.5"...
  • Page 89 Appendix B: System Specifications Regulatory Compliance FCC, ICES, CE, VCCI, RCM, NRTL, CB, UKCA Applied Directives, Standards Electromagnetic Compatibility Regulations 2016 FCC Part 15 ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN 55032 BS/EN 55035 CISPR 32 CISPR 35 BS/EN 61000-3-2 BS/EN 61000-3-3 BS/EN 61000-4-2 BS/EN 61000-4-3...
