  • Page 1 SuperServer ® SYS-530MT-H12TRF USER’S MANUAL Revision 1.0b...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Contents Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 System Features ........................9 Front View, System ......................9 Power Supply Indicator ....................9 Front View, Node .......................10 LAN Speed Indicator .....................10 Rear View ..........................11 Top View, Node .........................12 1.3 Motherboard Layout ......................13 Quick Reference .......................14 Motherboard Block Diagram .....................15 Chapter 2 Server Installation 2.1 Overview ..........................16...
  • Page 5 Contents 3.3 Processor and Heatsink Installation ...................24 Installing the LGA1200 Processor ..................24 Installing a Passive CPU Heatsink ..................27 Removing the Heatsink .....................27 3.4 Memory ..........................28 Memory Support ........................28 General Guidelines for Optimizing Memory Performance ..........28 Installing Memory ......................29 3.5 Motherboard Battery ......................30 3.6 Storage Drives ........................31 Checking the Temperature of an NVMe Drive ..............32 M.2 SSD ..........................33...
  • Page 6 7.10 Reporting an Issue ......................64 Technical Support Procedures ..................64 Returning Merchandise for Service ...................64 Vendor Support Filing System ..................65 7.11 Feedback ...........................65 7.12 Contacting Supermicro ......................66 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications BSMI RoHS Statement...
  • Page 7 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Overview The SuperServer SYS-530MT-H12TRF is a MicroCloud server system featuring twelve separate computing nodes. This chapter provides a brief outline of the functions and features. The following provides an overview of the specifications and capabilities. System Overview...

  • Page 9: System Features

    Indicates that the power supply has a warning condition and continues to operate. Indicates that the power supply is plugged in, and is in an abnormal state. The Solid Amber system might need service. Please contact Supermicro technical support. No AC power to modules...

  • Page 10: Front View, Node

    Two ports provided by the Supermicro Micro-LP network card LAN Speed Indicator LAN ports are provided by Supermicro Micro-LP network cards. The default configuration is two 1Gb/s ports. One LED indicates network activity; the other indicates the network speed. LAN LED (Speed Indicator)

  • Page 11: Rear View

    Chapter 1: Introduction Rear View Figure 1-3. System: Rear View...

  • Page 12: Top View, Node

    Slot for M.2 SSD, 2280 or 22110 CPU, Heatsink Intel Xeon E-2300 Family and Pentium series processor with heatsink Network Card Supermicro Micro-LP card providing LAN ports DIMM slots Four memory slots under and air shroud Storage Drives Two to four drives; two 3.5" drives shown...

  • Page 13: Motherboard Layout

    Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the X12STE-F motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4 or the Motherboard Manual.

  • Page 14: Quick Reference

    Chapter 1: Introduction Quick Reference Jumper Description Default Setting JBM1 IPMI Share LAN Enable/Disable Pins 1-2 Open (Enabled) JBT1 CMOS Clear Open (Normal) JPME2 Manufacturing Mode Pins 1-2 (Normal) JPO1 CPU Throttle When PWR_Fail Pins 2-3 (Disabled) JPT1 Onboard TPM 2.0 Enable/Disable Pins 1-2 (Enabled) JVRM1 VRM SMB Clock (to BMC or PCH)

  • Page 15: Motherboard Block Diagram

    Chapter 1: Introduction Motherboard Block Diagram Figure 1-8. Motherboard Block Diagram...

  • Page 16: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 3 for details on installing those specific components.

  • Page 17: Rack Precautions

    Chapter 2: Server Installation • This product is not suitable for use with visual display workplace devices according to §2 of the German Ordinance for Work with Visual Display Units. Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them.

  • Page 18: Airflow

    Chapter 2: Server Installation Airflow Equipment should be mounted into a rack so that the amount of airflow required for safe operation is not compromised. Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading.

  • Page 19: Installing The Rails

    Chapter 2: Server Installation 2.4 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. Also refer to the installation instructions that came with the rack. 1. The two rail sections are screwed together to keep them immobile during shipping. Release these screws just enough to allow the rails to slide apart.

  • Page 20: Installing The Server

    Chapter 2: Server Installation 2.5 Installing the Server 1. With one person on either side, lift the system and slide it onto the installed rails. 2. After pushing the enclosure all the way into the rack, use the thumbscrew on each side of the server to lock it into place.

  • Page 21: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 22: Servicing The System

    Chapter 3: Maintenance and Component Installation 3.2 Servicing the System Common maintenance tasks, such are replacing fans, power supply modules, or accessing the nodes, can be accomplished while the system is in the rack. Keep the system secure in the rack with the thumbscrews, because there are no locking latches in the rail system. Connecting to a Node USB, COM, and serial port capabilities can be added to any node through the KVM port on the front.

  • Page 23: Removing And Installing Nodes

    Chapter 3: Maintenance and Component Installation Removing and Installing Nodes The system features twelve removable nodes. Each node contains an individual motherboard and hard drives mounted on a sled, which allows it to easily be installed and removed from the chassis. Release Tab Handle Figure 3-2.

  • Page 24: Processor And Heatsink Installation

    • Thermal grease is pre-applied on new heatsinks. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • Graphics in this manual are for illustration only. Your components may look different. Installing the LGA1200 Processor 1.
  • Page 25 Chapter 3: Maintenance and Component Installation 2. Gently lift the load lever to open the load plate. Remove the plastic protective cover. Do not touch the CPU socket contacts. 3. Locate the triangle on the CPU and CPU socket, which indicates the location of Pin 1. Holding the CPU by the edges with your thumb and index finger, align the triangle on the CPU with the triangle on the socket.
  • Page 26 Chapter 3: Maintenance and Component Installation 5. Close the load plate, then gently push down the load lever into its locking position. CPU properly installed Load lever locked into place...

  • Page 27: Installing A Passive Cpu Heatsink

    12 lbf-in when tightening. Removing the Heatsink Note: Supermicro does not recommend that the CPU or heatsink be removed. However, if you must, please follow the instructions below to prevent damage to the CPU or other components.

  • Page 28: Memory

    General Guidelines for Optimizing Memory Performance JVR1 Supermicro recommends using memory of the same type, size, and speed. Mixed speeds can be installed, however all DIMMs will run at the speed of the slowest DIMM. Odd-numbers or memory modules (one or three modules) are supported. However, to achieve the best...

  • Page 29: Installing Memory

    Chapter 3: Maintenance and Component Installation Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge.

  • Page 30: Motherboard Battery

    Chapter 3: Maintenance and Component Installation 3.5 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system.

  • Page 31: Storage Drives

    Chapter 3: Maintenance and Component Installation 3.6 Storage Drives The fixed hard drives are installed directly to the node tray. It supports two 3.5", four 2.5", or a combination of one 3.5" and two 2.5" hard drives in each node tray. Enterprise level hard disk drives are recommended.

  • Page 32: Checking The Temperature Of An Nvme Drive

    Chapter 3: Maintenance and Component Installation Figure 3-12. Installing 2.5" Drives Checking the Temperature of an NVMe Drive There are two ways to check using the BMC Dashboard. Checking a Drive • BMC Dashboard > Server Health > NVMe SSD – Shows the temperatures of all NVMe drives.

  • Page 33: Ssd

    Chapter 3: Maintenance and Component Installation M.2 SSD The system supports one M.2 PCIe 4.0 x4/SATA 3.0 Key-M, with form factor 2280 or 22110. Standoff Hole for 22110 Standoff Hole for 2280 M.2 Slot with plastic lock pin Figure 3-13. M.2 Recepticles on the Motherboard Installing an M.2 SSD 1.

  • Page 34: System Cooling

    Chapter 3: Maintenance and Component Installation 3.7 System Cooling Fans Each three nodes each share a fan as described in the figure below. Fan 2 Fan 1 Fan 4 Fan 3 10 11 Figure 3-13. Corresponding Nodes and Fans...

  • Page 35: Replacing Fans

    Chapter 3: Maintenance and Component Installation Replacing Fans The four 9-cm fans can be replaced with no tools required and without opening the chassis. This may be done while the system is in the rack or on a bench. Replacing a Fan 1.

  • Page 36: Air Shroud, Node

    Chapter 3: Maintenance and Component Installation Air Shroud, Node The air shroud is used to concentrate airflow to maximize fan efficiency. The air shroud does not require screws. Installing the Air Shroud 1. Remove the node from the chassis onto a flat, non-conductive surface. 2.

  • Page 37: Power Supply

    • Solid Amber: When illuminated, indicates that the power supply is plugged in, and is in an abnormal state. The system might need service. Please contact Supermicro technical support. Changing the Power Supply 1. Unplug the AC cord from the module to be replaced.
  • Page 38 Chapter 3: Maintenance and Component Installation Figure 3-16. Replacing a Power Supply Module Release Tab Handle Figure 3-17. Release Tab on Power Supply Module...

  • Page 39: Expansion Module

    Chapter 3: Maintenance and Component Installation 3.9 Expansion Module Each node includes a Supermicro Micro-LP expansion module providing two LAN connections. Currently, there are four supported for this system. One Micro-LP PCIe 4.0 x8 slot One M.2 PCIe 4.0 x4 slot with SATA3 support, M-Key 2280/22110 Two NVMe U.2 PCIe x4 slots via the backplane...

  • Page 40: Chapter 4 Motherboard Connections

    The JTPM1 header is used to connect a Trusted Platform Module (TPM), which is available from Supermicro. A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the storage drive is not installed in the system.
  • Page 41 SATA 3.0 with DOM power receptacle connector and one SATA 3.0 right angle receptacle connector. SATA ports provide serial-link signal connections, which are faster than legacy Parallel ATA. Supermicro SuperDOMs are backward compatible with regular SATA HDDs or SATA DOMs that need external power cables.

  • Page 42: Input/Output

    Use this button to power on or off the node. Settings can be configured in the BIOS. KVM Connector Use the KVM port with a Supermicro cable (CBL-0218L) to provide video display, a COM port and two USB 2.0 ports (USB1/2) for your system.

  • Page 43: Jumpers

    Chapter 4: Motherboard Connections 4.3 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 44 Chapter 4: Motherboard Connections CPU Throttle When PWR_Fail The JPO1 jumper can enable the CPU Throttle mechanism to protect the CPU from damage due to excessive heat. This is a safeguard to prevent damage to the system. When an overheating condition occurs, thermal throttling kicks in. Three options are available to handle overheating: Power off, CPU Throttle—decrease CPU frequency to the minimum (800 Mhz), and Performance, or do nothing.

  • Page 45: Led Indicators

    Chapter 4: Motherboard Connections 4.4 LED Indicators Unit Identifier LED The Unit Idendifier LED (LED2) is located right next to the unit identifier switch on the back panel of the motherboard. Refer to p.33 for details about the LED.BMC Heartbeat LEDM1 is the BMC heartbeat LED.

  • Page 46: Chapter 5 Software

    1. Create a method to access the MS Windows installation ISO file. That can be a USB flash or media drive. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 47 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 48: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash or media drive.

  • Page 49: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 50: Bmc

    This can be found on a sticker on the chassis and a sticker on the motherboard. The sticker also displays the BMC MAC address. If necessary, the password can be reset using the Supermicro IPMICFG tool. Figure 5-5. BMC Password Label The sticker can be found on the pull-out service tag at the front of the chassis.

  • Page 51: Chapter 6 Optional Components

    Chapter 6: Optional Components Chapter 6 Optional Components This chapter describes alternate configurations and optional system components. Optional Parts Storage drive options Power options Cable Management Arm TPM security module Intel VROC RAID Key 6.1 Storage Protocols Supported The storage drive bays can support SATA, SAS, and NVMe in any combination. To enable SAS and NVMe, additional hardware is required.

  • Page 52: Chapter 7 Troubleshooting And Support

    Chapter 7 Troubleshooting and Support 7.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Menu Icon' Figure 7-1. Supermicro Website Click the menu icon, the three bars in the upper right corner, then select: •...

  • Page 53: Bmc Interface

    Security Center for recent security notices Supermicro Phone and Addresses 7.2 BMC Interface The system supports a Baseboard Management Controller (BMC) interface. It provides remote access, monitoring and management. There are several BIOS settings related to the BMC.

  • Page 54: Troubleshooting Procedures

    Chapter 7: Troubleshooting and Support 7.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service sections in this chapter. Power down the system before changing any non hot-swap hardware components.

  • Page 55: Losing The System Setup Configuration

    Also check the Control panel Overheat LED. • Adequate power supply: Make sure that the power supply provides adequate power to the system. Make sure that all power connectors are connected. Refer to the Supermicro website for the minimum power requirements. •...
  • Page 56 Chapter 7: Troubleshooting and Support • Remove a component in question from the chassis, and test it in isolation. Replace it if necessary. • Or swap in a new component for the suspect one. • Or install the possibly defective component into a known good system. If the new system works, the component is likely not the cause or the problem.

  • Page 57: Post Codes

    7.4 POST Codes The AMI UEFI BIOS supplies checkpoint codes, which are documented online at http://www. supermicro.com/support/manuals/ ("AMI BIOS POST Codes User's Guide"). When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, the POST codes can be viewed from the BMC using the Post Snooping function.

  • Page 58: Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 59 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 60 Chapter 7: Troubleshooting and Support Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
  • Page 61 Chapter 7: Troubleshooting and Support 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell]. Press <F4>...
  • Page 62 Chapter 7: Troubleshooting and Support Note: Do not interrupt this process until the BIOS flashing is complete. 9. The screen above indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system.

  • Page 63: Cmos Clear

    Chapter 7: Troubleshooting and Support 7.7 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1.

  • Page 64: Where To Get Replacement Components

    7.9 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com.

  • Page 65: Vendor Support Filing System

    For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 7.11 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. To provide feedback on our manuals, please email us at techwriterteam@...

  • Page 66: Contacting Supermicro

    San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 67: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 68 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 69 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 70 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 71 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 72 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
  • Page 73 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 74 Appendix A: Warning Statements ¡Advertencia! Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo. Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 75 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 76 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 77 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 78 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 79 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 80 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 81 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 82 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 83 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 84 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 85 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 86 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 87: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Intel Xeon E-2300 Family and Pentium series processors in a LGA 1200 socket with up to 95W Chipset Intel PCH C256 BIOS 256Mb AMI BIOS® SPI Flash BIOS ACPI 6.0, Plug and Play (PnP), BIOS rescue hot-key, and SMBIOS 3.0 or later Memory (per node) Four DIMM slots, up to 128GB DDR4 ECC and non-ECC VLP UDIMM, 3200Mhz Storage Drives...
  • Page 88 Appendix B: System Specifications Regulatory Compliance FCC, ICES, CE, UKCA, VCCI, RCM, NRTL, CB Certified Safety Models Compliant with UL and CSA: 939-22; 939-R22X12 Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN55032 BS/EN55035...

  • Page 89: Bsmi Rohs Statement

    Appendix B: System Specifications BSMI RoHS Statement 限 限 用 用 物 物 質 質 含 含 有 有 情 情 況 況 標 標 示 示 聲 聲 明 明 書 書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱: 伺服器/Server Equipment name 型號（型式）：...
  • Page 90 Appendix B: System Specifications 警告使用者 : 此為甲類資訊技術設備，於居住環境中使用時，可能會造成射頻擾動，在此種情況下， 使用者會被要求採取某些適當的對策。 輸入額定: 100-127V ~, 60-50Hz, 12-11A (x2) 200-240V ~, 60-50Hz, 10-9.5A (x2) *使用者不能任意拆除或替換內部配備 *報驗義務人之姓名或名稱：美超微電腦股份有限公司 *報驗義務人之地址：新北市中和區建一路 150 號 3 樓...
