LED Description
LED1 Unit Identifier (UID) LED
LED3 PCIe M.2-P2 Activity LED
LED4 Power LED
LED7001 PCIe M.2-P1 Activity LED
LEDM1 BMC Heartbeat LED
State: Status
Solid Blue: Unit Identified
Blinking Green: M.2-P2 Active
LED On: Onboard Power On
Blinking Green: M.2-P1 Active
Blinking Green: Device Working
