  • Page 1 SuperServer ® SYS-521AD-TN2 USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 System Features ........................9 Front View ...........................9 Control Panel ........................10 Rear View ..........................11 1.3 Motherboard Layout ......................12 Quick Reference Table ......................13 1.4 Chipset Block Diagram .......................15 Chapter 2 Maintenance and Component Installation 2.1 Removing Power ........................16 2.2 Hardware Security ......................16 Front Bezel Lock .......................16...
  • Page 5 Preface Replacing the Power Supply .....................37 Chapter 3 Motherboard Connections 3.1 Power Connections ......................38 3.2 Headers and Connectors ....................39 Control Panel .........................43 3.3 Input/Output Ports ......................46 Rear I/O Ports ........................46 3.4 Jumper Settings .........................48 How Jumpers Work ......................48 3.5 LED Indicators ........................51 Chapter 4 Software 4.1 Microsoft Windows OS Installation ..................52 4.2 Driver Installation ........................54...
  • Page 6 Preface Recovering the Main BIOS Block with a USB Device ............64 6.6 CMOS Clear ........................69 6.7 Where to Get Replacement Components ................70 6.8 Reporting an Issue ......................70 Technical Support Procedures ..................70 Returning Merchandise for Service ...................70 Vendor Support Filing System ..................71 6.9 Feedback ..........................71 Appendix A Standardized Warning Statements for AC Systems Appendix B System Specifications...
  • Page 7 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Chapter 1 Introduction

    Compact Mini-Tower, 9.45 x 8.27 x 11 in. / 240 x 210 x 279 mm (H x W x D) Notes: A Quick Reference Guide can be found on the product page of the Supermicro website. The following safety models associated with the SYS-521AD-TN2 have been certified as...

  • Page 9: System Features

    Chapter 1: Introduction 1.2 System Features The SYS-521AD-TN2 is a compact mini-tower. The following views of the system display the main features. Refer to Appendix B for additional specifications. Front View Fixed Drive Area Control Panel USB Ports Hot-Swap Drive Bays Lock Figure 1-1.

  • Page 10: Control Panel

    Chapter 1: Introduction Control Panel Power switches and status LEDs are located on the control panel on the front of the chassis. Power LED Power Button Drive Activity LED NIC LED Reset Button Information LED Figure 1-2. Control Panel Control Panel Features Feature Description The main power button applies or removes primary power from the power supply to the...

  • Page 11: Rear View

    Chapter 1: Introduction Rear View This section shows the system's rear view. The various I/O ports are located below the power supply. Power Supply RJ45 2.5 G LAN Port RJ45 GbE LAN Port DisplayPorts Mic In/Line In HDMI Ports USB Ports Figure 1-3.

  • Page 12: Motherboard Layout

    Chapter 1: Introduction 1.3 Motherboard Layout Below is a layout of the X13SAV-LVDS with the jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter JPL1 LAN2...

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) C1, JI SMB to PCIe Slots Enable/Disable Pins 2-3 (Disabled) JLCDPWR1 LVDS Panel VCC Power 3.3 V/5V Pins 1-2 (3.3 V) JPAC1 Audio Enable Pins 1-2 (Enabled) JPL1, JPL2 LAN1/LAN2 Enable/Disable Pins 1-2 (Enabled)
  • Page 14 Chapter 1: Introduction Connector Description JTPM1 Trusted Platform Module/Port 80 Connector LAN1, LAN2 LAN Ports LVDS1 Low Voltage Differential Signaling (LVDS) Connector MH1 - MH4 Mounting Holes P1_NVME0 I-SATA0/1/2/3 Ports (via OCuLink Connector) USB1/2, 3/4 Back Panel USB 3.2 Gen2 x1 Ports USB5/6 Front Accessible USB 2.0 Ports USB7/8...

  • Page 15: Chipset Block Diagram

    Chapter 1: Introduction 1.4 Chipset Block Diagram PCIe5.0_x16 PCIe x16 SLOT 32.0GT/s SVID INTEL IMVP9.1 PCIe4.0_x4 M.2 M KEY 16.0GT/s LGA1700 Digital port 1 Display Port DDI 1 DDR4 (CHA) DIMMA1 Digital port 2 3200MHz Display Port DDI 2 Digital port 3 DDR4 (CHB) HDMI1.4 DDI 3...

  • Page 16: Chapter 2 Maintenance And Component Installation

    Chapter 2: Maintenance and Component Installation Chapter 2 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components requires that power first be removed from the system.

  • Page 17: Rear System Hasp

    Chapter 2: Maintenance and Component Installation Figure 2-1. Front Bezel Lock Rear System Hasp Unauthorized entry through the rear of the chassis may be discouraged by placing a lock on the rear of the system. The chassis is equipped with a rear chassis hasp that can accommodate a variety of commonly available locks (not included).

  • Page 18: Accessing The System

    Chapter 2: Maintenance and Component Installation 2.3 Accessing the System The SYS-521AD-TN2 features a removable top cover to access to the inside of the chassis. Figure 2-4. Removing the Chassis Cover Removing the Top Cover 1. Power down the system as described in Section 2.1. 2.

  • Page 19: Processor And Heatsink Installation

    Thermal grease is pre-applied on a new heatsink. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • All graphics in this manual are for illustration purposess only. Your components may look different.
  • Page 20 Chapter 2: Maintenance and Component Installation 2. Gently push down the load lever to release and lift it, then lift the load plate to open it completely. Lever lock 3. Use your thumb and your index finger to hold the CPU. Align the small triangle maker and notches on the CPU to the corresponding triangle maker and notches on the CPU load bracket.
  • Page 21 Chapter 2: Maintenance and Component Installation 6. Close the load plate with the CPU inside the socket. Gently push the load lever down to the lever locks. Lever lock Attention! You can only install the CPU inside the socket in one direction. Make sure that it is properly inserted into the CPU socket before closing the load plate.

  • Page 22: Installing A Cpu Heatsink

    Chapter 2: Maintenance and Component Installation Installing a CPU Heatsink Note 1: The installation described in this section is for reference only. The actual in- stallation steps may vary depending on the CPU heatsink model. Refer to the heatsink instruction for more details. Note 2: Graphic drawings included in this manual are for reference only.
  • Page 23 Chapter 2: Maintenance and Component Installation 3. Attach the backplate into the mounting holes around the CPU socket on the bottom side of the motherboard. Backplate bottom side Motherboard bottom side Mounting hole Motherboard Top side...
  • Page 24 Chapter 2: Maintenance and Component Installation 4. Apply the proper amount of thermal grease on the CPU. 5. Place the heatsink on top of the CPU so that the four mounting holes on the heatsink are aligned with those on the retention mechanism. 6.

  • Page 25: Removing The Heatsink

    Chapter 2: Maintenance and Component Installation Removing the Heatsink Warning: We do not recommend that the CPU or heatsink be removed. However, if you do need to remove the heatsink, follow the instruction below to uninstall it to avoid damaging the CPU or other components.

  • Page 26: Memory

    Chapter 2: Maintenance and Component Installation 2.5 Memory Memory Support The SYS-521AD-TN2 supports up to 64 GB of DDR4 non-ECC SO-DIMM memory with speeds of up to 3200 MT/s in two memory slots. Refer to the table below for the recommended DIMM population order and additional memory information.

  • Page 27: Dimm Installation

    Chapter 2: Maintenance and Component Installation DIMM Installation 1. Install the desired number of SODIMMs into the memory slots, starting with DIMMA1 and then DIMMB1. 2. Align the key on the bottom of the SODIMM module against the receptive point on the memory slot.

  • Page 28: Motherboard Battery

    Chapter 2: Maintenance and Component Installation 2.6 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system.

  • Page 29: System Components

    Chapter 2: Maintenance and Component Installation 2.7 System Components Installing Expansion Cards The SYS-521AD-TN2 includes a PCIe 5.0 x16 slot to support one low-profile expansion card. The card is installed by removing the chassis tray that holds the motherboard and the rear I/O shield.
  • Page 30 Chapter 2: Maintenance and Component Installation 8. Slide the rear tray into the chassis and secure it with the screws. 9. Replace the chassis cover and power up the system. Figure 2-7. Installing the Expansion Card...

  • Page 31: Front-Mounted Hot-Swap Drives

    Chapter 2: Maintenance and Component Installation Front-Mounted Hot-Swap Drives The SYS-521AD-TN2 supports four hot-swap drives mounted in carriers that are accessible from the front of the chassis. These drives may be removed and installed without powering down the system. Removing 3.5" Hot-Swap Drives 1.
  • Page 32 Chapter 2: Maintenance and Component Installation Drive Dummy Drive Drive Carrier Figure 2-9. Installing a Drive into a Drive Carrier Installing a Drive Carrier into the Drive Cage 1. Insert the drive carrier into the drive bay, using the drive carrier handle to push it all the way into the drive cage until it stops.

  • Page 33: Installing The Internal Fixed Drives

    Chapter 2: Maintenance and Component Installation Installing the Internal Fixed Drives The SYS-521AD-TN2 system supports two internal 2.5" fixed drives (one top-mounted drive and one side-mounted drive) and one DVD-ROM drive. Installing a Top-Mounted Fixed Drive 1. Power down the system as described in Section 2.1 and remove the chassis cover. 2.
  • Page 34 Chapter 2: Maintenance and Component Installation Installing a Side-Mounted Fixed Drive 1. Power down the system as described in Section 2.1 and remove the chassis cover as described in Section 2.3. 2. Place a 2.5" drive into the drive bracket and secure the drive to the bracket with the four screws provided.

  • Page 35: Adding An M.2 Storage Card

    Chapter 2: Maintenance and Component Installation Adding an M.2 Storage Card One M.2 SSD card (M-Key, 2280 form factor) may be installed on the motherboard. 1. Remove power from the system as described in Section 2.1 and remove the chassis cover.

  • Page 36: Installing A Fan

    Chapter 2: Maintenance and Component Installation Installing a Fan The system includes a single 12-cm rear exhaust fan. The chassis also features a set of mounting holes that will support a standard 9-cm exhaust fan (not included). Installing the Exhaust Fan 1.

  • Page 37: Replacing The Power Supply

    Chapter 2: Maintenance and Component Installation Replacing the Power Supply The SYS-521AD-TN2 includes a single (non-hot-swap) 350 W power supply. If it is necessary to replace the power supply, follow the instructions below. Changing the Power Supply 1. Power down the system as described in Section 2.1 and remove the chassis cover. 2.

  • Page 38: Chapter 3 Motherboard Connections

    Chapter 3: Motherboard Connections Chapter 3 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 39: Headers And Connectors

    Chapter 3: Motherboard Connections 3.2 Headers and Connectors Fan Headers There are three 4-pin fan headers on the motherboard. Although pins 1-3 of the fan headers are backward compatible with the traditional 3-pin fans, we recommend you use 4-pin fans to take advantage of the fan speed control via Pulse Width Modulation through the thermal management.
  • Page 40 Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Go to the following link for more information on the TPM: http://www.supermicro.com/manuals/other/TPM.pdf. Trusted Platform Module Header Pin Definitions...
  • Page 41 Chapter 3: Motherboard Connections LVDS Connector LVDS1 is the LVDS connector. Low-voltage differential signaling (LVDS) is a high-speed digital interface that operates at low power. It is a type of connection that is mostly used with monitors. LVDS Connector Pin Definitions Pin# Definition Pin#...
  • Page 42 Chapter 3: Motherboard Connections OCuLink Connector (P1_NVMe0) The X13SAV-LVDS features one internal OCuLink connector offering four SATA ports via break-out cable for additional storage interface. COM Header The motherboard has one COM header that provides one serial connection (COM1) and supports RS-232 function.

  • Page 43: Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 44 Chapter 3: Motherboard Connections Overheat (OH)/Fan Fail Connect an LED cable to pins 7 and 8 of the Front Control Panel to use the Overheat/Fan Fail LED connections. The LED on pin 8 provides warnings of overheating or fan failure. Refer to the tables below for pin definitions.
  • Page 45 Chapter 3: Motherboard Connections NMI Button The non-maskable interrupt (NMI) button header is located on pins 19 and 20 of JF1. Refer to the table below for pin definitions. NMI Button Pin Definitions (JF1) Pins Definition Control Ground...

  • Page 46: Input/Output Ports

    Chapter 3: Motherboard Connections 3.3 Input/Output Ports Rear I/O Ports See the figure below for the locations and descriptions of the I/O ports on the rear of the motherboard. Figure 3-2. Rear I/O Ports Rear I/O Ports Description Description Description LAN1 USB4 (3.2) HDMI 2.0b...
  • Page 47 Chapter 3: Motherboard Connections LAN Ports One 2.5 Gigabit (LAN1) and one 1 Gigabit (LAN2) Ethernet ports are located on the I/O back panel. These ports accept RJ45 cables. Refer to the table below for pin definitions. LAN Port Pin Definition Pin# Definition Pin#...

  • Page 48: Jumper Settings

    Chapter 3: Motherboard Connections 3.4 Jumper Settings How Jumpers Work To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. See the diagram below for an example of jumping pins 1 and 2.
  • Page 49 Chapter 3: Motherboard Connections Watch Dog Timer Watchdog (JWD1) is a system monitor that can reboot the system when a software application hangs. Close pins 1-2 to reset the system if an application hangs. Close pins 2-3 to generate a non-maskable interrupt (NMI) signal for the application that hangs. Refer to the table below for jumper settings.
  • Page 50 Chapter 3: Motherboard Connections LVDS Power Voltage Use the JLCDPWR1 jumper to select the power voltage for the LVDS panel. Make sure that the specifications of the cable is compatible with the panel to prevent damage. LVDS Voltage Selection Jumper Settings Jumper Setting Definition Pins 1-2...

  • Page 51: Led Indicators

    Chapter 3: Motherboard Connections 3.5 LED Indicators LAN LEDs Two LAN ports (LAN 1/2) are located on the I/O back panel of the motherboard. Each Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED may be green, orange, or off to indicate the speed of the connection.

  • Page 52: Chapter 4 Software

    1. Create a method to access the Microsoft Windows installation ISO file. That can be a USB flash or media drive. 2. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash or media drive.
  • Page 53 Chapter 4: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 4-2.

  • Page 54: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash or media drive.

  • Page 55: Superdoctor ® 5

    4.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 56: Ipmi

    (BMC) and other management controllers distributed among different system modules.There are several BIOS settings that are related to IPMI. For general documentation and information on IPMI, visit our website at: http://www.supermicro.com/products/nfo/IPMI. cfm. BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 57: Chapter 5 Optional Components

    Chapter 5: Optional Components Chapter 5 Optional Components This chapter describes optional system components and installation procedures. 5.1 Optional Parts List Optional Parts List Description Part Number Cable CBL-0044L DVM-TEAC-DVDRW-SBT5 DVD kit MCP-220-81502-0N Heatsink SNK-P0092AP4-1...

  • Page 58: Chapter 6 Troubleshooting And Support

    Chapter 6 Troubleshooting and Support 6.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Products Figure 6-1. Supermicro Website • Specifications for servers and other hardware are available by clicking the menu icon, then selecting the Products option.

  • Page 59: Baseboard Management Controller Interface

    Security Center for recent security notices Supermicro Phone and Addresses 6.2 Baseboard Management Controller Interface The system supports the Baseboard Management interface. BMC is used to provide remote access, monitoring and management. There are several BIOS settings that are related to BMC.

  • Page 60: Troubleshooting Procedures

    Chapter 6: Troubleshooting and Support 6.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service section(s) in this chapter. Power down the system before changing any non hot-swap hardware components.

  • Page 61: No Video

    Chapter 6: Troubleshooting and Support No Video If the power is on but you have no video, remove all the add-on cards and cables. Then power up the system again to see if you then have video. System Boot Failure If the system does not display POST (Power-On-Self-Test) or does not respond after the power is turned on, check the following: Turn on the system with only one DIMM module installed.
  • Page 62 2. Memory support: Make sure that the memory modules are supported by testing the modules using memtest86 or a similar utility. Note: Refer to the product page on our website at http://www.supermicro.com for memory and CPU support and updates. 3. Storage drive support: Make sure that all storage drives work properly. Replace the bad drives with good ones.

  • Page 63: Crash Dump Using Bmc

    Chapter 6: Troubleshooting and Support 6.4 Crash Dump Using BMC In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using BMC.

  • Page 64: Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 65 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 66 Chapter 6: Troubleshooting and Support Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
  • Page 67 Chapter 6: Troubleshooting and Support 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell]. Press <F4>...
  • Page 68 Chapter 6: Troubleshooting and Support Note: Do not interrupt this process until the BIOS flashing is complete. 9. The screen above indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system.

  • Page 69: Cmos Clear

    Chapter 6: Troubleshooting and Support 6.6 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1.

  • Page 70: Where To Get Replacement Components

    6.7 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com.

  • Page 71: Vendor Support Filing System

    For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 6.9 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. Please email us at techwriterteam@supermicro.com to provide feedback on our manuals.

  • Page 72: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 73 Appendix A: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 74 Appendix A: Warning Statements . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 75 Appendix A: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 76 Appendix A: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 77 Appendix A: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components (except for hot-swap components). 電源切断の警告...
  • Page 78 Appendix A: Warning Statements ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 79 Appendix A: Warning Statements Attention Seul le personnel autorisé et le personnel de maintenance qualifié doivent être autorisés à installer, remplacer ou entretenir cet équipement.. !‫אזהרה‬ ‫.יש לאפשר רק צוות מורשה ואנשי שירות מוסמכים להתקין, להחליף או לטפל בציוד זה‬ ‫.ينبغي...
  • Page 80 Appendix A: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 81 Appendix A: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 82 Appendix A: Warning Statements ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 83 Appendix A: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 84 Appendix A: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 85 Appendix A: Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 86 Appendix A: Warning Statements ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 87 Appendix A: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 88 Appendix A: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 89 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 90 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 91 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 92: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processor Support Single 13th Gen Intel Core i9/Core i7/Core i5/Core i3/Pentium/Celeron processor supports up to 65 W TDP Chipset Intel® Q670E BIOS AMI 256 MB SPI Flash ACPI 6.1, PCI FW 3.0, RTC (Real Time Clock) Wakeup, SMBIOS 3.0 or later, UEFI 2.7 Memory Two DIMM slots for up to 64 GB DDR4-3200 MT/s SO-DIMM Storage Drives...
  • Page 93 Appendix B: System Specifications Power Supply Model: PWS-353-1H (single 350 W power module, 80+ Gold level) Total Output Power and Input 350 W with Input 100 - 240 Vac AC Input Frequency 50-60 Hz Output Type 24 pin ATX -12 V Max: 0.3 A / Min: 0.05 A +12 V Max: 28 A / Min: 0.1 A (100 Vac - 240 Vac)
  • Page 94 Appendix B: System Specifications Applied Directives, Standards Electromagnetic Compatibility Regulations 2016 FCC Part 15 ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN 55032 BS/EN 55035 CISPR 32 CISPR 35 BS/EN 61000-3-2 BS/EN 61000-3-3 BS/EN 61000-4-2 BS/EN 61000-4-3 BS/EN 61000-4-4 BS/EN 61000-4-5 BS/EN 61000-4-6 BS/EN 61000-4-8 BS/EN 61000-4-11...
