1.1 Overview

This chapter provides an outline of the functions and features of the SuperServer SYS-511R-ML.
This is a high-performance 1U server ideal for web hosting, application server, embedded
server, SMB file server, and Network appliance. The following provides an overview of the
specifications and capabilities.
Motherboard
X13SCH-SYS
Chassis
CSE-512F-350B1
Supports a single Intel Xeon E-2400 processor, in socket V0 (LGA 1700) with up to eight
Processors
cores
Up to 128 GB of DDR5 ECC UDIMM memory with speeds of up to 4400 MT/s in four
Memory
memory slots
Fixed internal SATA drives: two 3.5" drives or three 2.5" drives
Storage
Two M.2 PCIe 4.0 x4 M-Key NVMe
Expansion Slots
One PCIe 5.0 x16, FHHL
LANs: Two 1 GbE ports; one dedicated port for BMC
USB: five USB 3.2 Gen 1 ports (2 rear, 2 headers, 1 Type A)
I/O Ports
Six USB 2.0 ports (2 rear, 4 headers)
VGA, two Serial (1 rear, 1 header)
(Optional) DVD drive
Two 4-cm counter-rotating fans with speed control
System Cooling
CPU heatsink and air shroud to direct air flow
Power
One power supply 350W, high- efficiency, 80Plus Platinum level
Form Factor
1U Rackmount, 17.2 x 1.7 x 14.5 in. (437 x 43 x 368 mm) (WxHxD)
A Quick Reference Guide can be found on the
The following safety models associated with the SYS-511R-ML have been certified as
compliant with UL and CSA: 512F-S3X13, 512F-3, 512-3.
Chapter 1
Introduction
System Overview
product page
8
Chapter 1: Introduction
of the Supermicro website.
