Rear View

Power Supply

Input/Output Panel

1
2
# Description
1 COM1
2 VGA
3 BMC LAN
4 USB0 (USB 2.0)
Feature Description
The unit identification (UID) button turns on or off the blue light function of the
UID Switch/LED/
Information LED and a blue LED on the rear of the chassis.
BMC button
This button can also be used to
BMC LAN Port Dedicated port for access to the BMC; for LED details, see
Input/Output Panel
Figure 1-3. System: Rear View
3 6 8
4 7 9
5
Figure 1-4. Input/Output Panel
Rear I/O Ports
# Description
5 USB1 (USB 2.0)
6 USB6 (USB 3.2 Gen1)
7 USB7 (USB 3.2 Gen1)
8 LAN2
Input/Output Panel
reset the
11
Chapter 1: Introduction
PCIe Slots
10
# Description
9 LAN1
10 UID Switch
BMC.
BMC LAN LEDs
