Quick Reference

Jumper Description
JBT1 CMOS Clear
JPG1 VGA Enable/Disable
JPME2 ME Manufacturing Mode
JWD1 Watchdog Timer
Connector
BMC_LAN
B1
COM1
COM2
FAN1–FAN5
FANA, FANB
JBPNI C1
2
JF1
JIPMB1
JL1
JPCIE4
JPCIE6
JPCIE7
JPI C1
2
JPW1
JPW2
JS1
JSEN1
JTPM1
JUIDB1
LAN1–LAN2
M.2-P1
M.2 NVME,
M.2-P2
M.2 NVME
MH1–MH7, MH12
MH10–MH11, MH13–MH14
USB0/1
USB2/3, USB4/5
USB6/7
USB8
USB9/10
VGA
Description
Dedicated BMC LAN Port
Onboard Battery
COM Port
COM Header
System Fan Headers (FAN1: CPU Fan)
4-pin BMC External I C Header
2
Front Control Panel Header
4-pin BMC External I C Header (for an IPMI card)
2
Chassis Intrusion Header
PCH SLOT4 PCIe 4.0 x4 (in x8) Slot
CPU SLOT6 PCIe 5.0 x16 Slot
CPU SLOT7 PCIe 4.0 x4 (in x8) Slot
Power I C System Management Bus (Power SMB) Header
2
24-pin ATX Power Connector
8-pin CPU Power Connector
Intel PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10 support)
Inlet Sensor Header
Trusted Platform Module/Port 80 Connector
UID Switch
1GbE I210 LAN Ports
M.2 PCIe 4.0 x4 Slots from PCH(Supports M-Key 2280 and 22110)
Mounting Holes
M.2 Mounting Holes
Back Panel USB 2.0 Ports
Front Accessible USB 2.0 Headers
Back Panel USB 3.2 Gen 1 Ports
Front Accessible USB 3.2 Gen 1 Type-A Header
Front Accessible USB 3.2 Gen 1 Header
VGA Port
14
Chapter 1: Introduction
Default Setting
Open (Normal)
Pins 1–2 (Enabled)
Pins 1–2 (Normal)
Pins 1–2 (Reset)
