Figure 66. Dry airside pressure drop at 0.075 lb/cu.ft. 90 to 130 ton evaporator coil
Evaporator Dry Airside Pressure Drop at 0.075 lb/cu.ft. 20-130 Ton
2.0
1.0
0.9
0.8
0.7
0.6
0.5
0.4
0.3
0.2
0.1
4000
RT-SVX072D-EN
6000 800010000
Unit Airflow, CFM
20000 40000
Unit Start-up
60000
