Trane IntelliPak 1 with Symbio 800 Installation, Operation And Maintenance Manual page 143

Table 73. Value for parameter 4–14 (Motor Speed High Limit)
Digit # 5,6,7 (Unit Tonnage)
20,25
30
40
50-55
60
70-75
20 - 75
90 - 130
Table 74. Relief/return fan VFD parameters
Menu ID
0-01
0-03
Operation Display
0-06
0-40
1-20
1-22
1-23
1-24
Load and Motor
1-25
1-73
1-90
2-00
Brakes
2-01
2-04
RT-SVX072D-EN
DDP Fans - (Digit # 14 = B thru H, J thru N, P, R, T thru Z)
Digit # 2 = A, X
(4 Pole)
81
75
67
61
75
67
FC Fans - (Digit #14= 1 thru 9, A)
FC Fans - (Digit #14= C thru G)
Description Parameter Setting
Language [0] English US
Regional Settings [1] North American
Set to applicable unit power supply
[102] 200-240V/60Hz for 208 & 230V/60Hz units
[122] 440-480V/60Hz for 460V/60Hz units
Grid Type [132] 525-600V/60Hz for 575V/60Hz units
[12] 380-440v/50Hz for 380 & 415V/50Hz supply
For IT Grid (no ground connections) or Corner grounded Delta power supply systems, the
applicable voltage/Hz and IT-Grid or Delta should be selected.
[Hand on] - Key on LCP [0] Disabled
Motor Power (KW/HP) Per Motor Nameplate HP - KW
Motor Voltage (V) Per Motor Nameplate Voltage
Motor Frequency (HZ) Per Motor Nameplate Frequency
Motor Current (A) Per Motor Nameplate FLA
Motor Nominal Speed
Per Motor Nameplate Rated Speed
(RPM)
Flying Start [1] Enabled
Motor Thermal
[4] ETR Trip1
Protection
DC Hold / Preheat
[0] 0%
Current (%)
DC Brake Current (%) [0] 0%
DC Brake Cut In Speed [10] 10 Hz
(6 Pole)
83
60
60
Service and Maintenance
Digit # 2 = F
(4 Pole) (6 Pole)
75
67
61
83
61
61
61
143
