Trane IntelliPak 1 with Symbio 800 Installation, Operation And Maintenance Manual page 71

Figure 45. Supply fan performance with or without variable frequency drive — 30 ton air-cooled, - forward curved
8.0
7.5
1400 RPM
7.0
6.5
1300 RPM
6.0
5.5
1200 RPM
5.0
1100 RPM
4.5
4.0
1000 RPM
3.5
900 RPM
3.0
2.5
800 RPM
2.0
700 RPM
1.5
600 RPM
1.0
500 RPM
0.5
0.0
0 2000
Important: Maximum static pressure leaving the rooftop is
4.0" H O positive. The static pressure drops
2
from the supply fan to the space cannot
exceed 4.0" H
RT-SVX072D-EN
4000 6000
Airflow, CFM
O.
2
8000 10000 12000
Notes:
• Shaded areas represent selectable area.
Contact your local Trane® representative for
more information.
• Supply fan performance curve includes internal
resistance of rooftop. For total static pressure
determination, system external static must be
added to appropriate component static
pressure drops (evaporator coil, filters, optional
economizer, optional relief fan, optional heating
system, optional cooling only extended casing,
optional roof curb).
• Maximum Cfm (for cULus approval) as follows:
30 ton - 13,500 Cfm.
• Minimum motor horsepower is 5 hp. Maximum
motor horsepower is 20 hp. Maximum fan RPM
is 1450.
Unit Start-up
70%
80%
90%
14000
71
