Dimensional Data
Figure 6. S_H_ cooling and heating units (90-130 ton)
6' 7⅜"
6' 1⅝"
14' 6¾"
14' 4¾"
14' 0 ⁹⁄₃ "
14' 2 ⁹⁄₃ "
13' 4⅛"
12' 11⅛"
8½"
Main Unit
Control Box
9 ⁄₃ "
21 ⁵⁄₃ "
10' 0⅝"
11' 10 ⁵⁄₃ "
22
Lifting Lug
(6 points)
1⅜" Drain Hole
(both sides)
3' 9"
7' 0"
Supply Air
Opening
2' 4"
3½" Diameter Hole
4¹¹⁄₁₆" Diameter Hole
for Gas Piping
for Steam or Hot Water Piping
Relief Air
1" Condensate Drain
(both sides)
CPVC Furnace Drain
(See CPVC Dimensional Table)
Legend
A, B, C, D = 1⅛" diameter hole for field-installed
control wiring.
E = 3½" diameter hole for for main power wiring.
7⁹⁄₃ "
Electric or Gas
Control Box
21' 5⅜"
Outdoor Air
6' 9⅜"
1⅜" Drain Hole
(both sides)
Note: Ultra Low Leak Pwer Relief Damper
extends 0.65" beyaond lifting lugs.
9' 1"
Return Air
Opening
5⅞"
