Unit Start-up
WARNING
Rotating Components!
Failure to disconnect power before servicing could
result in rotating components cutting and slashing
technician which could result in death or serious
injury.
During installation, testing, servicing and
troubleshooting of this product it may be necessary
to work with live and exposed rotating components.
Have a qualified or licensed service individual who
has been properly trained in handling exposed
rotating components, perform these tasks.
7. Press the TEST START key to start the test.
Remember that the delay designated in step 6 must
elapse before the fan will begin to operate.
8. Once the system has started, verify that the electric
heat or the hydronic heat system is operating properly
by using appropriate service technics; i.e. amperage
readings, delta tees, etc.
9. Press the STOP key at the User Interface Module in the
unit control panel to stop the system operation.
Electric, Steam and Hot Water
Start-Up
1. Ensure that the "System" selection switch at the remote
panel is in the Off position.
2. Close the disconnect switch or circuit protector switch
that provides the supply power to the unit terminal block
(2XD1 on 20-75T units / 1XD1 on 90-130T units)or the
unit-mounted disconnect switch (2QB1 on 20-75T units
/ 1QB1 on 90-130T units).
WARNING
Hazardous Voltage!
Failure to disconnect power before servicing could
result in death or serious injury.
Disconnect all electric power, including remote
disconnects before servicing. Follow proper lockout/
tagout procedures to ensure the power can not be
inadvertently energized. Verify that no power is
present with a voltmeter.
Important: Do not open the service access doors while
the unit is operating. HIGH VOLTAGE IS
PRESENT AT TERMINAL BLOCK OR
UNIT DISCONNECT SWITCH.
3. Turn the 115 volt control circuit switch (1S1) to the "On"
position.
Turn the 115 volt control circuit switch (1S20) to the
"On" position. (90-130T units only)
4. Press the Manual Override key to display the first
service screen. Refer to the latest edition of the
appropriate programming manual for VAV applications
118
for the Manual Override screens and programming
instructions.
5. Program the following system components for
operation by scrolling through the displays:
Electric Heat
Heat Stages - 1, 2, or 3 (as required)
Steam or Hot Water Heat
Hydronic Heat Actuator (100% Open)
Open the main steam or hot water valve supplying the
rooftop heater coils.
6. Once the configuration for the appropriate heating
system is complete, press the Auto key.
WARNING
Rotating Components!
Failure to disconnect power before servicing could
result in rotating components cutting and slashing
technician which could result in death or serious
injury.
During installation, testing, servicing and
troubleshooting of this product it may be necessary
to work with live and exposed rotating components.
Have a qualified or licensed service individual who
has been properly trained in handling exposed
rotating components, perform these tasks.
7. Press the Auto key to start the test. Remember that the
delay designated in step 6 must elapse before the fan
will begin to operate.
8. Once the system has started, verify that the electric
heat or the hydronic heat system is operating properly
by using appropriate service technics; i.e. amperage
readings, delta tees, etc.
9. Press the STOP key and clear all Manual Overrides in
the unit control panel to stop the system operation.

Gas Furnace Startup

WARNING
Hazardous Gases and Flammable
Vapors!
Failure to observe the following instructions could
result in exposure to hazardous gases, fuel
substances, or substances from incomplete
combustion, which could result in death or serious
injury. The state of California has determined that
these substances may cause cancer, birth defects, or
other reproductive harm.
Improper installation, adjustment, alteration, service
or use of this product could cause flammable
mixtures or lead to excessive carbon monoxide. To
avoid hazardous gases and flammable vapors follow
proper installation and setup of this product and all
warnings as provided in this manual.
