Trane IntelliPak 1 with Symbio 800 Installation, Operation And Maintenance Manual page 76

Unit Start-up
Figure 50. Supply fan performance with variable frequency drive - 40 ton cooling only - direct drive plenum, 120%
width
8.0
7.5
7.0
6.5
6.0
1600 RPM
5.5
1500 RPM
5.0
4.5
1400 RPM
4.0
1300 RPM
3.5
1200 RPM
3.0
1100 RPM
2.5
1000 RPM
2.0
1.5
1.0
0.5
0.0
0 2000 4000
Important: Maximum static pressure leaving the rooftop is
4.0" H O positive. The static pressure drops
2
from the supply fan to the space cannot
exceed 4.0" H
76
1900 RPM
1800 RPM
1700 RPM
6000 8000 10000
Airflow, CFM
O.
2
12000 14000 16000
Notes:
• Shaded areas represent selectable area.
Contact your local Trane® representative for
more information.
• Supply fan performance curve includes internal
resistance of rooftop. For total static pressure
determination, system external static must be
added to appropriate component static
pressure drops (evaporator coil, filters, optional
economizer, optional relief fan, optional heating
system, optional cooling only extended casing,
optional roof curb).
• Maximum Cfm (for cULus approval) as follows:
40 ton - 18,000 Cfm.
• Minimum motor horsepower is 3 hp. Maximum
motor horsepower is 25 hp. Maximum fan RPM
is 1,900.
18000 20000
RT-SVX072D-EN
