Figure 55. Supply fan performance with variable frequency drive - 60 ton cooling only air-cooled - direct drive plenum,
80% width
8.0
7.5
2000 RPM
7.0
1900 RPM
6.5
6.0
1800 RPM
5.5
1700 RPM
5.0
1600 RPM
4.5
1500 RPM
4.0
1400 RPM
3.5
1300 RPM
3.0
1200 RPM
2.5
1100 RPM
2.0
1000 RPM
1.5
1.0
0.5
0.0
0 2500 5000
Important: Maximum static pressure leaving the rooftop is
4.0" H O positive. The static pressure drops
2
from the supply fan to the space cannot
exceed 4.0" H
RT-SVX072D-EN
2100 RPM
7500 10000 12500 15000
Airflow, CFM
O.
2
2200 RPM
17500 20000 22500
Notes:
• Shaded areas represent selectable area.
Contact your local Trane® representative for
more information.
• 60 ton units with gas heat use the 30" DDP fans.
See
• Supply fan performance curve includes internal
resistance of rooftop. For total static pressure
determination, system external static must be
added to appropriate component static
pressure drops (evaporator coil, filters, optional
economizer, optional relief fan, optional heating
system, optional cooling only extended casing,
optional roof curb).
• Maximum Cfm (for cULus approval) as follows:
60 ton - 27,000 Cfm.
• Minimum motor horsepower is 10 hp (2 x 5 hp
motors). Maximum motor horsepower is 40 hp
(2 x 20 hp motors). Maximum fan RPM is 2,200.
25000 27500 30000
Figure 61, p. 87 .
