Unit Start-up
Figure 60. Supply fan performance with variable frequency drive - 60, 70, and 75 tons gas heat, direct drive plenum,
100% width
8.0
7.5
7.0
6.5
6.0
5.5
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0 5000
Important: Maximum static pressure leaving the rooftop is
4.0" H O positive. The static pressure drops
2
from the supply fan to the space cannot
exceed 4.0" H
86
1700 RPM
1600 RPM
1500 RPM
1400 RPM
1300 RPM
1200 RPM
1100 RPM
1000 RPM
10000 15000
O.
2
20000 25000
Airflow, CFM
Notes:
• Shaded areas represent selectable area.
Contact your local Trane® representative for
more information.
• Supply fan performance curve includes internal
resistance of rooftop. For total static pressure
determination, system external static must be
added to appropriate component static
pressure drops (evaporator coil, filters, optional
economizer, optional relief fan, optional heating
system, optional cooling only extended casing,
optional roof curb).
• Maximum Cfm (for cULus approval) as follows:
60, 70, and 75 tons gas heat - 27,000 Cfm.
• Minimum motor horsepower is 10 hp (2 x 5 hp
motors). Maximum motor horsepower is 30 hp
(2 x 15 hp motors). Maximum fan RPM is 1,500.
30000 35000
