MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
input In8 (or less if the number of inputs selected is less than 8) is the MSB (most significant
bit).
Example of operator with 8 inputs:
In1 → 0
In2 → 1
In3 → 1
In4 → 0
In5 → 1
In6 → 0
In7 → 0
In8 → 1
Decimal value equal to 150.
The user could choice among various operation listed below:
•
< (Lower) The OUT output will be 1 (TRUE) as long as the input value is less than
the decimal value set as constant. The OUT output will be set to 0 (FALSE) when the
input value is higher than or equal to the decimal value set as constant.
•
>= (Higher) or equal The OUT output will be 1 (TRUE) as long as the input value is
higher than or equal to the decimal value set as constant. The OUT output will be
set to 0 (FALSE) when the input value is lower than the decimal value set as constant.
•
> (Higher)
than the decimal value set as constant. The OUT output will be set to 0 (FALSE) when
the input value is lower than or equal to the decimal value set as constant.
• <= (Lower or equal) The OUT output will be 1 (TRUE) as long as the input value is
lower than or equal to the decimal value set as constant. The OUT output will be set
to 0 (FALSE) when the input value is higher than the decimal value set as constant.
•
= (Equal) The OUT output will be 1 (TRUE) as long as the input value is equal to
the decimal value set as constant. The OUT output will be set to 0 (FALSE) when the
input value is different from the decimal value set as constant.
•
!= (Different) The OUT output will be 1 (TRUE) as long as the input value is different
from the decimal value set as constant. The OUT output will be set to 0 (FALSE) when
the input value is equal to the decimal value set as constant.
8540780 • 25/01/2023 • Rev.43
The OUT output will be 1 (TRUE) as long as the input value is higher
Example of operator with 5 inputs:
In1 → 0
In2 → 1
In3 → 0
In4 → 1
In5 → 1
Decimal value equal to 26.
