Hardware Installation and Reference Guide
4

Appendix

4.1

Connectors and Media

1000BASE-T/100BASE-TX/10BASE-T Port
The 1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000 Mbps port with auto-
negotiation, which supports auto MDI/MDIX Crossover at these three rates.
The 1000BASE-T complies with IEEE 802.3ab standard, and uses up to 100 m (328.10
100-ohm CAT5e
The 1000BASE-T port uses four pairs of wires for transmission, all of which must be
connected. Table 4-1
port.
Table 4-1 Four Twisted Pairs of the 1000BASE-T
In addition to the preceding cables, the 100BASE-TX/10BASE-T can also use 100-ohm
Category-3, Category-4, and Category-5 cables for 10 Mbps, and 100-ohm Category-5
cables for 100 Mbps, both of which can be up to 100 m
pinouts of the 100BASE-TX/10BASE-T.
Table 4-2 Pinouts of the 100BASE-TX/10BASE-T
UTP or STP twisted pairs with
shows the connection of the twisted pairs used by the 1000BASE-T
higher standard
(328.10
22
Appendix
(STP is recommended).
ft). Table 4-2 shows the
ft) of
