Hardware Installation and Reference Guide
device.
The power supply and required current are available in the installation location.

The network cables have been deployed in the installation location.

3.3

Precautions

The RG-AP680(CD) can be mounted on a wall or a pole with a diameter ranging from 50
mm to 140 mm (1.97 in. to 5.51 in.). Use the 304 stainless steel hose clamp delivered with
the AP. If the diameter of the pole is out of this range, purchase the SUS304 hose clamp
with a proper size for installation. The thickness of the hose clamp should be at least 2.5
mm (0.10 in.). Otherwise, the AP could fall down and cause injuries. The installation site
should be determined by the technical personnel who conducts a site survey.
To ensure the normal operation of the AP and lengthen the service life of the AP, observe
the following precautions before installing the AP.
Before connecting the power supply, make sure the external power supply matches

the power module inside the AP.
Before connecting the power cord, make sure the power switch is in the OFF position.

When connecting a wire to a grounding stud, make sure their colors are the same.

Make sure the power supply is properly connected.

3.4

Installing the Access Point

(1) Use four M5 screws to secure the AP to the mounting plate.
