INSTALLATION PROCEDURES
CONNECTION DIAGRAMS
1.1 One-to-one connection
WWW.TECHLY.COM
8
1) Press to restart
2) Press and hold for 5 seconds
to restore the factory settings,
and then let go when the power
indicator flashes
Insert the SFP optical module
(T1550nm/R1310nm)
Connect with HDMI display device
Connect with DC 5V/2A power adapter
HDMI OPTICAL
FIBER EXTENDER
9
10
