HDMI EXTENDER
4K@60HZ
Receiver (RX)
Reset button
RJ45 signal
input
IR in
Power indicator
DC5V power
HDMI output
3.5 mm stereo
output

INSTALLATION PROCEDURES

Connection diagram
Press to restart the device
Connect with network cable
Connect with IR receiver extension cable
When there is power and no HDMI signal, the indicator will flash,
when there is HDMI signal, the indicator will light solid
Connect with DC5V/1A power adapter
Connect with HDMI display device with HDMI cable
Connect with earphone or speaker
7
