3.4.2

Connecting the leak sensor

3.5

Column oven

930 Compact IC Flex Oven/ChS (2.930.2200)
Route the loose end into a waste container.
Plugging in the leak sensor connection cable
The leak sensor connection cable is coiled up in the base tray.
1 Pull the leak sensor connection cable out of the base tray as far as
needed.
2 Plug the plug for the leak sensor connection cable into the leak sen-
sor connection socket (labeled Leak Sensor).
The column oven ensures that the separation takes place at a constant
temperature. It is firmly sealed by the instrument's smaller door and is well
insulated. The capillaries are fed through openings on the edge of the col-
umn oven, so that they do not get pinched when the door is closed. The
temperature of the column oven can be configured in the software.
The column oven is completely connected. No installation work is
required.
