3.11.2.4 Connecting the rinsing solution
930 Compact IC Flex Oven/ChS (2.930.2200)
3 Use a pressure screw (6.2744.070) and an adapter (6.2744.080) to
fasten the other end of the PTFE capillary to Port 1 of the Dosino.
4 Connect the FEP tubing (6.1805.120) from the bottle with the regen-
eration solution to Port 2 of the Dosino.
Various possibilities exist for rinsing the Metrohm Suppressor Module:
Rinsing solution via STREAM (recommended)
￭
Use the eluent from the conductivity detector as rinsing solution.
Rinsing solution via Dosino
￭
Prepare the rinsing solution in a separate bottle and convey it with a
Dosino.
The rinsing solution is connected to the rinsing solution capillary.
Connecting the rinsing solution inlet with STREAM
1 Connect the detector outlet capillary of the conductivity detector and
the capillary labeled rinsing solution to each other using a coupling
(6.2744.040) and two pressure screws (6.2744.070).
NOTE
The detector outlet capillary must not be shortened.
Connecting the rinsing solution inlet to the Dosino
The rinsing solution capillary can be connected to the Dosino to which the
regenerant capillary is already connected.
For this step, you need the following accessories: (not contained in its
entirety in the standard accessories):
3 short pressure screws (6.2744.070)
￭
