3.11.1

Inserting the rotors

Accessories
930 Compact IC Flex Oven/ChS (2.930.2200)
6.2842.020
6.2842.000
NOTE
The instruments are supplied without rotor and without adapter.
The suitable rotor and the adapter, if required, must be ordered sepa-
rately.
For this step, you need the following accessories:
For suppression: MSM Rotor A (6.2832.000) or MSM‑HC Rotor A
￭
(6.2842.000), MSM‑LC Rotor A (6.2844.000) or MSM‑HC Rotor C
(6.2842.200) or MSM-HC Rotor C (6.2842.200)
Optional: Adapter (6.2842.020)
￭
Connecting piece (6.2835.010)
￭
Large rotors can be inserted directly into the rotor housing.
CAUTION
The rotor may be destroyed during start-up if not inserted correctly.
Therefore, follow the following instructions exactly.
6.2842.020
6.2844.000
6.2832.000
