Introduction

The RUGGEDCOM RSG920P is a rugged, high density, Ethernet switch designed
to operate in harsh environments with widely varying climatic and environmental
conditions. Tested and certified to withstand extreme temperatures, vibrations
and shocks, the RUGGEDCOM RSG920P offers exceptional reliability for industrial
applications, such as transportation systems and oil/gas applications.
Offering 20 Gigabit Ethernet ports, including four SFP slots and four Power-over-
Ethernet (PoE) ports, the RUGGEDCOM RSG920P is suitable for applications that
require high bandwidths and is ready to accommodate future network expansions.
•
•
The small form factor of the RUGGEDCOM RSG920P allows for installation in space-
limited cabinets and on DIN rails.
RUGGEDCOM ROS provides advanced layer 2 networking functions, and advanced
cyber security features. Coupled with the ruggedized hardware design, RUGGEDCOM
RSG920P is ideal for creating mission-critical, real-time, control applications where
high reliability and availability is of paramount importance.
1.1

Feature Highlights

Ethernet Ports and Inputs
•
•
•
•
RUGGEDCOM RSG920P
Equipment Manual, 10/2023, C79000-G8976-1172-09
The four SFP slots provide ultimate flexibility in up-link distances and bandwidth,
with support for Gigabit and Fast Ethernet.
The four PoE ports supply up to 120 W (30 W per port) of power, allowing the
RUGGEDCOM RSG920P to accommodate various PoE devices, such as cameras,
intercom devices, Wireless LAN Access points and Bluetooth sensors. Smart
Power Management options provide higher reliability for the most important
devices on the network when power demands exceed the available supply.
16 x 10/100/1000Base-TX RJ-45 Ports
4 x 100/1000Base-TX/FX/SX/LX SFP Ports
Note
A separate power supply is required for PoE Ports
4 x IEEE 802.3at PoE (Power over Ethernet) Ports (30 W per port max, 120 W
aggregate total)
Two isolated digital inputs
