Rear Panel; Rear Panel View - H3C UniServer R4900 G6 Ultra Manual

Port
connector

Rear panel

Rear panel view

Figure 9 Rear panel components
Table 9 Rear panel description
Item
1
2
3
4
5
6
7
8
9
10
11
For more information about the serial & DSD module, see
Type Description
NOTE:
The server supports only Xiaomi USB Wi-Fi adapters.
Description
PCIe riser bay 1: PCIe slots 1 through 3
PCIe riser bay 2: PCIe slots 4 through 6
PCIe riser bay 3: PCIe slots 7 and 8
PCIe riser bay 4: PCIe slots 9 and 10
Power supply 2
Power supply 1
OCP 3.0 network adapter/Serial & DSD module (in slot 17) (optional)
VGA connector
Two USB 3.0 connectors
HDM dedicated network port (1Gbps, RJ-45, default IP address 192.168.1.2/24)
OCP 3.0 network adapter (in slot 16) (optional)
"Serial & DSD
7
module."
