Server specifications

Components

Figure 1 Server components
Item
(1) Chassis access panel
(2) Mid drive cage
(3) Standard
adapter
(4) System battery
(5) Storage controller
(6) NVMe VROC module
(7) GPU module
(8) Riser card
(9) OCP adapter
(10) Serial & DSD module
(11) Memory
Description
N/A
Installed in the server to accommodate drives.
PCIe network
Installed in a standard PCIe slot to provide network ports.
Supplies power to the system clock to ensure system time correctness.
Provides RAID capability to SAS/SATA drives, including RAID
configuration and RAID scale-up. It supports online upgrade of the
controller firmware and remote configuration.
Works with Intel VMD to provide RAID capability for the server to
virtualize storage resources of NVMe drives.
Provides computing services such as graphics processing and AI.
Provides PCIe slots.
Provides one slot for installing an OCP network adapter and two slots for
installing drives at the server rear.
Provides one serial port and two SD card slots.
Stores computing data and data exchanged with external storage
