Item
5
6
2, 3, 4, 7,
and 8

DIMM slots

The system board provides eight DIMM channels per processor, and 16 channels in total, as shown
in Figure 14. Each channel contains two DIMM slots.
Figure 14 System board DIMM slot layout
Description
username and password of a valid HDM
user account.
On—HDM login requires the default
•
username and password.
Off (default)—Normal server startup.
•
On—Restores the default BIOS settings.
•
Off (default)—Normal server startup.
•
On—Clears all passwords from the
•
BIOS at server startup.
Reserved for future use.
Remarks
you complete tasks with the default username
and password as a best practice.
To restore the default BIOS settings, turn on
and then turn off the switch. The server starts
up with the default BIOS settings at the next
startup.
CAUTION:
The server cannot start up when the switch is
turned on. To avoid service data loss, stop
running services and power off the server
before turning on the switch.
If this switch is on, the server will clear all the
passwords at each startup. Make sure you turn
off the switch before the next server startup if
you do not need to clear all the passwords.
N/A
