PCA-R4900-4GPU-G6
Figure 54 PCA-R4900-4GPU-G6 (1)
(1) PCIe5.0 x16 (8,4,2,1) slot 14
(3) PCIe5.0 x16 (8,4,2,1) slot 12
(5) GPU module power connector
PCIe5.0 x16 (8,4,2,1) description:
•
PCIe5.0: Fifth-generation signal speed.
x16: Connector bandwidth.
•
(8,4,2,1): Compatible bus bandwidth, including x8, x4, x2, and x1.
•
Figure 55 PCA-R4900-4GPU-G6 (2)
(7) GPU module power connector
(2) PCIe5.0 x16 (8,4,2,1) slot 13
(4) PCIe5.0 x16 (8,4,2,1) slot 11
(6) GPU module power connector
(8) GPU module power connector
36
