Rear 4LFF SAS/SATA drive backplane

The PCA-BP-4LFF-2U-G6 4LFF SAS/SATA drive backplane is installed at the server rear to support

four 3.5-inch SAS/SATA drives.

Figure 38 4LFF SAS/SATA drive backplane

(1) AUX connector (AUX)

(3) x4 Mini-SAS-HD connector (SAS PORT)

The PCA-BP-2SFF-2U-G6 2SFF SAS/SATA drive backplane is installed at the server rear to support

two 2.5-inch SAS/SATA drives.

Figure 39 2SFF SAS/SATA drive backplane

(1) Power connector (PWR)

(3) AUX connector (AUX)

The PCA-BP-2SFF-2UniBay-2U-G6 2SFF UniBay drive backplane is installed at the server rear to

support two 2.5-inch SAS/SATA/NVMe drives.

(2) Power connector (PWR)

(2) x4 Mini-SAS-HD connector (SAS PORT)
