Figure 66 NVMe M.2 expander module
(1) NVMe M.2 SSD card slot 1
Server management module
The server management module is installed on the system board to provide I/O connectors and
HDM out-of-band features for the server.
Figure 67 Server management module
(1) VGA connector
(2) NVMe M.2 SSD card slot 2
(2) Two USB 3.0 connectors
44
