No. Description
2 PCIe riser connector 2 (for processor 2)
3 Fan connector 2 for the OCP 3.0 network adapter
OCP 3.0 network adapter connector 2/Serial & DSD
4
module connector
5 PCIe riser connector 1 (for processor 1)
6 Server management module slot
7 Fan connector 1 for the OCP 3.0 network adapter
8 OCP 3.0 network adapter connector 1
9 SlimSAS connector 3 (x4 SATA)
10 AUX connector 9 for mid drive backplane
11 Mid drive backplane/Riser card AUX connector 7
12 SlimSAS connector 2 (x4 SATA)
13 SlimSAS connector 1 (x4 SATA or M.2 SSD)
14 Front I/O connector
15 M.2 SSD AUX connector
16 Fan connector 4
17 Liquid Leakage Detection module connector
18 LCD smart management module connector
19 MCIO connector C1-P4A (for processor 1)
20 MCIO connector C1-P4C (for processor 1)
21 Fan connector 3
22 MCIO connector C1-P3C (for processor 1)
23 MCIO connector C1-P3A (for processor 1)
24 Power connector 3 for front drive backplane
25 Power connector 2 for front drive backplane
26 Connector for the thermal sensor module at the air inlet
27 Power connector 1 for front drive backplane
28 Fan connector 2
29 MCIO connector C2-P4A (for processor 2)
30 AUX connector 3 for front drive backplane
31 MCIO connector C2-P4C (for processor 2)
32 MCIO connector C2-P3C (for processor 2)
33 Fan connector 1
34 AUX connector 2 for front drive backplane
35 AUX connector 1 for front drive backplane
36 MCIO connector C2-P3A (for processor 2)
37 Chassis-open alarm module connector
11
Mark
RISER2 PCIe X16
-
OCP2&DSD&UART CARD
RISER1 PCIe X16
BMC
OCP1 FAN
OCP1
SATA PORT3
AUX9
AUX7
SATA PORT2
M.2&SATA PORT1
RIGHT EAR
M.2 AUX
J245
LEAKDET
DIAG LCD
C1-P4A
C1-P4C
J104
C1-P3C
C1-P3A
PWR3
PWR2
-
PWR1
J94
C2-P4A
AUX3
C2-P4C
C2-P3C
J96
AUX2
AUX1
C2-P3A
INTRUDER
