(1) SLOT 2 cable
(3) PCIe5.0 x16 (8,4,2,1) slot 8
(5) Power connector
PCIe5.0 x16 (8,4,2,1) description:
PCIe5.0: Fifth-generation signal speed.
•
x16: Connector bandwidth.
•
•
(8,4,2,1): Compatible bus bandwidth, including x8, x4, x2, and x1.
RC-5HHHL-R5-2U-G5
Figure 53 RC-5HHHL-R5-2U-G5
(1) PCIe5.0 x16 (8,4,2,1) slot 12
(3) PCIe5.0 x16 (8,4,2,1) slot 13
(5) PCIe5.0 x16 (8,4,2,1) slot 14
(7) PCIe5.0 x16 (8,4,2,1) slot 15
(9) Power connector
PCIe5.0 x16 (8,4,2,1) description:
PCIe5.0: Fifth-generation signal speed.
•
x16: Connector bandwidth.
•
•
(8,4,2,1): Compatible bus bandwidth, including x8, x4, x2, and x1.
(2) AUX connector
(4) PCIe5.0 x16 (8,4,2,1) slot 7
(6) SLOT 1 cable
(2) MCIO connector 2
(4) MCIO connector 3
(6) MCIO connector 4
(8) MCIO connector 5
(10) AUX connector
