Figure 45 RC-3FHFL-2U-G6 (2)
(5) MCIO connector 2-C
(7) MCIO connector 1-A
PCIe5.0 x16 (16,8,4,2,1) description:
PCIe5.0: Fifth-generation signal speed.
•
x16: Connector bandwidth.
•
(16,8,4,2,1): Compatible bus bandwidth, including x16, x8, x4, x2, and x1.
•
(6) MCIO connector 2-A
(8) MCIO connector 1-C
29
