Figure 47 RC-3FHHL-2U-G6 (2)
(4) MCIO connector 1-A
PCIe5.0 x16 (16,8,4,2,1) description:
PCIe5.0: Fifth-generation signal speed.
•
x16: Connector bandwidth.
•
(16,8,4,2,1): Compatible bus bandwidth, including x16, x8, x4, x2, and x1.
•
RC-FHHL-2U-G6
Figure 48 RC-FHHL-2U-G6
(1) PCIe5.0 x16 (16,8,4,2,1) slot 3/6*
PCIe5.0 x16 (16,8,4,2,1) description:
(5) MCIO connector 1-C
(2) Rear 2SFF SAS/SATA drive backplane
31
