Chapter 4: Web configuration
MAC table learning
If the learning mode for a given port is greyed out, another module is in control of the
mode so that it cannot be changed by the user. An example of such a module is the
MAC-Based Authentication under 802.1X.
Object
Auto
Disable
Secure
Static MAC table configuration
The static entries in the MAC table are shown in this table. The static MAC table can
contain 64 entries. The MAC table is sorted first by VLAN ID and then by MAC address.
Object
Delete
VLAN ID
MAC Address
Port Members
Adding a New Static Entry
Buttons
• Click Apply to apply changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
MAC address table status
Dynamic MAC table
Entries in the MAC table are shown on this page. The MAC table contains up to 8192
entries and is sorted first by VLAN ID, then by MAC address.
310
Description
Learning is done automatically as soon as a frame with
unknown SMAC is received.
No learning is done.
Only static MAC entries are learned, all other frames are
dropped.
Note: Make sure that the link used for managing the switch
is added to the Static Mac Table before changing to secure
learning mode, otherwise the management link is lost and
can only be restored by using another non-secure port or by
connecting to the switch via the serial interface.
Description
Select to delete the entry. It will be deleted during the next
save.
The VLAN ID of the entry.
The MAC address of the entry.
Checkmarks indicate which ports are members of the entry.
Select or deselect as needed to modify the entry.
Click Add New Static Entry
MAC table. Specify the VLAN ID, MAC address, and port
members for the new entry. Click Save.
NS4702-24P-4X-V2 Managed Switch User Manual
to add a new entry to the static
