Object
TCP/UDP Source
Filter
TCP/UDP Source No.
TCP/UDP Source
Range
TCP/UDP Destination
Filter
TCP/UDP Destination
Number
TCP/UDP Destination
Range
TCP FIN
TCP SYN
TCP RST
NS4702-24P-4X-V2 Managed Switch User Manual
Description
Specify the TCP/UDP source filter for this ACE.
Any: No TCP/UDP source filter is specified (TCP/UDP source filter status is
"don't-care").
Specific: To filter a specific TCP/UDP source filter with this ACE, you can
enter a specific TCP/UDP source value. A field for entering a TCP/UDP
source value appears.
Range: To filter a specific TCP/UDP source range filter with this ACE, you
can enter a specific TCP/UDP source range value. A field for entering a
TCP/UDP source value appears.
When Specific is selected for the TCP/UDP source filter, you can enter a
specific TCP/UDP source value. The allowed range is
that hits this ACE matches this TCP/UDP source value.
When Range is selected for the TCP/UDP source filter, you can enter a
specific TCP/UDP source range value. The allowed range is
frame that hits this ACE matches this TCP/UDP source value.
Specify the TCP/UDP destination filter for this ACE.
Any: No TCP/UDP destination filter is specified (TCP/UDP destination filter
status is "don't-care").
Specific: To filter a specific TCP/UDP destination filter with this ACE, you
can enter a specific TCP/UDP destination value. A field for entering a
TCP/UDP destination value appears.
Range: To filter a specific range TCP/UDP destination filter with this ACE,
you can enter a specific TCP/UDP destination range value. A field for
entering a TCP/UDP destination value appears.
When Specific is selected for the TCP/UDP destination filter, you can enter
a specific TCP/UDP destination value. The allowed range is
frame that hits this ACE matches this TCP/UDP destination value.
When Range is selected for the TCP/UDP destination filter, you can enter a
specific TCP/UDP destination range value. The allowed range is
A frame that hits this ACE matches this TCP/UDP destination value.
Specify the TCP "No more data from sender" (FIN) value for this ACE.
0: TCP frames where the FIN field is set must not be able to match this
entry.
1: TCP frames where the FIN field is set must be able to match this entry.
Any: Any value is allowed ("don't-care").
Specify the TCP "Synchronize sequence numbers" (SYN) value for this
ACE.
0: TCP frames where the SYN field is set must not be able to match this
entry.
1: TCP frames where the SYN field is set must be able to match this entry.
Any: Any value is allowed ("don't-care").
Specify the TCP "Reset the connection" (RST) value for this ACE.
0: TCP frames where the RST field is set must not be able to match this
entry.
1: TCP frames where the RST field is set must be able to match this entry.
Any: Any value is allowed ("don't-care").
Chapter 4: Web configuration
0 to 65535. A frame
0 to 65535. A
0 to 65535. A
0 to 65535.
